Page 12
360101-XTG-B-0508
12
Johnson Controls Unitary Products
TABLE 10: ELECTRICAL DATA
MODEL
DEB
POWER
SUPPLY
VOLTAGE
LIMITATIONS
1
COMPRESSOR COND.
FAN
MOTOR,
FLA
SUPPLY
AIR
BLOWER
MOTOR
FLA
MINIMUM
CIRCUIT
AMPACITY
MAX.
FUSE
2
SIZE,
AMPS
MAX.
HACR
BREAKER
SIZE,
AMPS
UNIT
POWER
FACTOR
TRANSFORMER
SIZE (VA)
MIN.
MAX.
RLA
LRA
30
208/230-1-60
187
253
14.7
73
1.1
2.6
22.1
30
30
0.96
40
36
208/230-1-60
187
253
17.3
94
1.1
3.5
26.2
35
35
0.96
40
42
208/230-1-60
187
253
15.5
86
1.1
3.5
23.9
30
30
0.96
40
48
208/230-1-60
187
253
24.4
140
1.3
4.0
35.8
45
45
0.96
40
60
208/230-1-60
187
253
28.9
165
1.3
4.0
44.4
60
60
0.96
40
36
208/230-3-60
187
253
10.9
78.0
1.1
3.5
18.2
25
25
0.96
75
42
208/230-3-60
187
253
11.5
88.0
1.1
3.5
19.0
25
25
0.96
75
48
208/230-3-60
187
253
14.1
105.0
0.7
4.0
22.3
30
30
0.96
75
60
208/230-3-60
187
253
16.0
125.0
1.3
7.0
28.3
40
40
0.96
75
36
460-3-60
414
504
5.8
40.0
0.6
1.8
9.6
15
15
0.96
75
42
460-3-60
414
504
5.8
42.0
0.6
1.8
9.7
15
15
0.96
75
48
460-3-60
414
504
7.1
55.0
0.6
2.0
11.5
15
15
0.96
75
60
460-3-60
414
504
8.0
67.0
0.7
3.5
14.2
20
20
0.96
75
36
575-3-60
518
630
4.5
32.0
0.4
1.5
7.6
15
15
0.96
75
42
575-3-60
518
630
5.8
44.0
0.4
1.5
9.1
15
15
0.96
75
48
575-3-60
518
630
5.6
44.0
0.6
1.6
9.3
15
15
0.96
75
60
575-3-60
518
630
6.4
50.0
0.6
2.8
11.4
15
15
0.96
75
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element, time delay type.
ELECTRIC HEAT
CORRECTION
FACTORS
NOMINAL VOLTAGE VOLTAGE
KW CAP.
MULTIPLIER
240
208
230
.75
.92
480
460
.92
600
575
.92
TABLE 11: ELECTRICAL DATA (COOLING / ELECTRIC HEAT)
MODEL
DEB
POWER
SUPPLY
COMPRESSOR
COND. FAN
MOTORS
SUPPLY
AIR
BLOWER
MOTOR
ELECTRIC HEAT ACCESSORY
MCA
(AMPS)
MAX FUSE/
SIZE
1
(AMPS)
MAX HACR
2
BREAKER SIZE
RLA
LRA
FLA
FLA
MODEL NO.
STAGE
KW
TOTAL AMPS
030
208/230-1-60
12.0
73.0
1.1
2.6
2NH04500506
1
3.8/5.0*
18.1/20.8
25.8/29.3
30/30
30/30
2NH04500706
2
5.6/7.5*
27.3/31.3
37.1/42.3
40/45
40/45
2NH04501006
2
7.5/10.0*
36.1/41.7
48.4/55.3
50/60
50/60
2NH04501506
2
11.3/15.0*
54.2/62.5
71.0/81.4
80/90
80/90
036
208/230-1-60
17.3
94.0
1.1
3.5
2NH04501006
2
7.5/10.0*
36.1/41.7
49.5/56.5
50/60
50/60
2NH04501506
2
11.3/15.0*
54.2/62.5
72.1/82.5
80/90
80/90
042
208/230-1-60
15.5
86.0
1.1
3.5
2NH04500506
1
3.8/5.0*
18.1/20.8
26.9/30.4
35/35
35/35
2NH04500706
2
5.6/7.5*
27.1/31.3
38.2/43.4
40/45
40/45
2NH04501006
2
7.5/10.0*
36.1/41.7
49.5/56.5
50/60
50/60
2NH04501506
2
11.3/15.0*
54.2/62.5
72.1/82.5
80/90
80/90
048
208/230-1-60
24.4
140.0
1.3
4.0
2NH04501006
2
7.5/10.0*
36.1/41.7
50.1/57.1
60/60
60/60
2NH04501506
2
11.3/15.0*
54.2/62.5
72.1/83.1
80/90
80/90
2NH04502006
2
15.0/20.0*
72.2/83.3
95.3/109.2
100/110
100/110
2NH04502506
2
18.8/25.0*
90.3/104.2
117.8/135.2
125/150
125/150
060
208/230-1-60
38.0
165.0
1.3
7.0
2NH04501006
2
7.5/10.0*
36.1/41.7
53.9/60.8
70/70
70/70
2NH04501506
2
11.3/15.0*
54.2/62.5
76.5/86.9
80/90
80/90
2NH04502006
2
15.0/20.0*
72.2/83.3
99.0/112.9
100/125
100/125
2NH04502506
2
18.8/25.0*
90.3/104.2
121.6/139.0
125/150
125/150
036
208/230-3-60
10.9
78.0
1.1
3.5
2NH04501025
1
7.5/10.0*
20.8/24.1
30.4/34.4
35/35
35/35
2NH04501525
1
11.3/15.0*
31.3/36.1
43.5/49.5
45/50
45/50
