H I G H C A P A C I T Y S T A CK E R ( H C S ) A C C E S S O R I E S
D O C U C O L O R 2 0 6 0 / 2 0 4 5 O P E R A T O R M A N U A L
AC
CESSO
RIES
5–23
Control Panel
Figure 12. HCS Control Panel
Name Function
1 Ready Indicator The Ready Indicator blinks when the digital press is
being initialized. The Ready Indicator is constant when
in use or in standby.
2 Table Down
Switch Press once to lower the elevator and unlock the front
HCS door. Press again to stop the elevator from
lowering. If pressed while running a job, all sheets in the
paper path are delivered before the elevator will lower.
3 Ready To Open Illuminates when the elevator has reached the down
position and the Stacker Door can be opened.
