P A P E R A N D P A P E R T R A Y S
D O C U C O L O R 2 0 6 0 / 2 0 4 5 O P E R A T O R M A N U A L
PA
P
E
R
A
N
D
PA
P
E
R
TR
A
Y
S
3–15
4
Although Trays 1, 2, and 3 have auto size detection capability, the paper weight
(g/m
2
) range must be selected on the Weight Indicator. Selecting the correct
paper weight range affects the feed performance and Image Quality. Press the
selection button until the light next to the correct weight is illuminated.
Tray 1 has a chart which converts pounds into g/m
2
for easy selection, or refer to
the Paper Weight Conversion Tables in this chapter.
NOTE: The Indicator light will illuminate for the paper weight selected. The
Indicator is on the frame of the digital press to the right of the tray and can only
be seen when the tray is pulled out.
Figure 7. Paper Trays 1 and 2 Weight Indicator on the Frame
Selection
Button
