Manual de instrucciones de PM5D/PM5D-RH
Sección de referencia
353
Información mos-
trada en pantalla
Menú de
funciones
Funciones
globales
Funciones
de salida
Funciones
de entrada
Apéndices
❏ Hum & Noise
EIN= Equivalent Input Noise
* Hum & Noise is measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation.
❏ Dynamic Range
* Dynamic range is measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation.
❏ Input Indicator Level
❏ Sampling Frequency
Input
Output
RL
Conditions
Min.
Typ.
Max.
Unit
INPUT 1-48
STEREO A,B
600
Ω
Master fader at nominal level and one INPUT fader at nomi-
nal level.
–128
EIN
dBu
PM5D:
Rs= 150
Ω, GAIN: Max., PAD: Off
–64
PM5D-RH:
Rs= 150
Ω, GAIN: Max.
–62
Master fader at nominal level and one INPUT fader at nomi-
nal level.
PM5D:
Rs= 150
Ω, GAIN: Min., PAD: On
PM5D-RH:
Rs= 150
Ω, GAIN: Min.
–81
–76
All INPUT
Master fader at nominal level and all INPUT1-48 faders at
nominal level.
PM5D:
Rs= 150
Ω, GAIN: Min., PAD: On
PM5D-RH:
Rs= 150
Ω, GAIN: Min.
–64
2TR IN ANALOG 1,2
STEREO A,B
600
Ω
Master fader at nominal level.
Rs= 150
Ω
–81
–76
—
STEREO A,B
600
Ω
Residual Output Noise, ST Master Off
–86
MIX OUT
Residual Output Noise, MIX Master Off
MATRIX OUT
Residual Output Noise, MATRIX Master Off
MONITOR OUT
Residual Output Noise, MONITOR Level Control Min.
CUE OUT
Residual Output Noise, CUE Level Control Min.
PHONES
8
Ω
Residual Output Noise, PHONES Level Control Min.
Input
Output
RL
Conditions
Min.
Typ.
Max.
Unit
INPUT 1-48
STEREO A,B
600
Ω
PM5D:
AD + DA, GAIN: Min.,
PAD: On
Fs= 44.1/48 kHz
108
dB
PM5D-RH:
AD + DA, GAIN: Min.
Fs= 88.2/96 kHz
106
—
STEREO A,B
DA Converter
110
MIX OUT
MATRIX OUT
MONITOR OUT
CUE OUT
Input
Output
Condition
Min.
Typ.
Max.
Unit
INPUT 1-48
INSERT OUT
PEAK Red LED: ON
19
21
23
dBu
SIGNAL Green LED: ON
–12
–10
–8
ST IN 1-4
PEAK Red LED: ON
19
21
23
SIGNAL Green LED: ON
–12
–10
–8
Parameter
Conditions
Min.
Typ.
Max.
Unit
External Clock
Frequency Range
Normal Rate
39.69
50.88
kHz
Double Rate
79.39
101.76
Internal Clock
Frequency
Word Clock : Int 44.1kHz
44.1
Word Clock : Int 48kHz
48
Word Clock : Int 88.2kHz
88.2
Word Clock : Int 96kHz
96
Accuracy
Word Clock : Int 44.1kHz
50
ppm
Word Clock : Int 48kHz
Word Clock : Int 88.2kHz
Word Clock : Int 96kHz
Jitter
Word Clock : Int 44.1kHz
5
ns
Word Clock : Int 48kHz
Word Clock : Int 88.2kHz
Word Clock : Int 96kHz
