Detailed Description
X-Ref Target - Figure 1-27
NET "GPIO_LED_0" LOC = "E13";
NET "GPIO_LED_1" LOC = "C14";
NET "GPIO_LED_2" LOC = "C4";
NET "GPIO_LED_3" LOC = "A4";
NET "GPIO_SWITCH_0"
LOC = "D14";
NET "GPIO_SWITCH_1"
LOC = "E12";
NET "GPIO_SWITCH_2"
LOC = "F12";
NET "GPIO_SWITCH_3"
LOC = "V13";
NET "GPIO_BUTTON0"
LOC = "P4";
NET "GPIO_BUTTON1"
LOC = "F6";
NET "GPIO_BUTTON2"
LOC = "E4";
NET "GPIO_BUTTON3"
LOC = "F5";
NET "CPU_RESET" LOC = "N4";
NET "GPIO_HDR0" LOC = "N17";
NET "GPIO_HDR1" LOC = "M18";
NET "GPIO_HDR2" LOC = "A3";
NET "GPIO_HDR3" LOC = "L15";
NET "GPIO_HDR4" LOC = "F15";
NET "GPIO_HDR5" LOC = "B4";
NET "GPIO_HDR6" LOC = "F13";
NET "GPIO_HDR7" LOC = "P12";
Figure 1-27:
UCF Location Constraints for User and General-Purpose I/O
