Xilinx SP601 Hardware UG518 User Manual
Page 21
SP601 Hardware User Guide
21
UG518 (v1.1) August 19, 2009
Detailed Description
H16
FLASH_A6
23
A6
H15
FLASH_A7
22
A7
H14
FLASH_A8
20
A8
H13
FLASH_A9
19
A9
F18
FLASH_A10
18
A10
F17
FLASH_A11
17
A11
K13
FLASH_A12
13
A12
K12
FLASH_A13
12
A13
E18
FLASH_A14
11
A14
E16
FLASH_A15
10
A15
G13
FLASH_A16
8
A16
H12
FLASH_A17
7
A17
D18
FLASH_A18
6
A18
D17
FLASH_A19
5
A19
G14
FLASH_A20
4
A20
F14
FLASH_A21
3
A21
C18
FLASH_A22
1
A22
C17
FLASH_A23
30
A23
F16
FLASH_A24
56
A24
R13
FPGA_D0_DIN_MISO_MISO1
33
DQ0
T14
FPGA_D1_MISO2
35
DQ1
V14
FPGA_D2_MISO3
38
DQ2
U5
FLASH_D3
40
DQ3
V5
FLASH_D4
44
DQ4
R3
FLASH_D5
46
DQ5
T3
FLASH_D6
49
DQ6
R5
FLASH_D7
51
DQ7
M16
FLASH_WE_B 55
WE_B
L18
FLASH_OE_B
54
OE_B
Table 1-7:
BPI Memory Connections (Cont’d)
FPGA U1 Pin
Schematic Netname
BPI Memory U10
Pin Number
Pin
