PHYSICAL AND ELECTRICAL DATA - 3 PHASE
MODEL
H1RD
030S25
H1RD
036S25
H1RD
042S25
H1RD
048S25
H1RD
060S25
H1RD
030S46
H1RD
036S46
H1RD
042S46
H1RD
048S46
H1RD
060S46
Unit Supply Voltage
208-230V, 3
φ, 60Hz
460V, 3
φ, 60Hz
Normal Voltage Range
1
187 to 252
432 to 504
Minimum
Circuit
Ampacity
14.3 14.3 12.4 21.5 23.1 6.9 9.6 6.9 10.3 11.3
Max. Overcurrent Device Amps
2
20 20 20 35 40 15 15 15 15 15
Min. Overcurrent Device Amps
3
15
15
15
25
25
15
15
15
15
15
Compressor Type
4
Recip Recip Recip ScrollB
ScrollB Recip Recip Recip ScrollB
ScrollB
Compressor Amps
Rated
Load
10.2 10.2 8.8 16.0 17.3 4.9 13.5 11.8 7.7 8.4
Locked
Rotor
72 72 72 115
123 45 45 45 50 70
Crankcase
Heater
No No No No No No No No No No
Fan
Motor
Amps
Rated
Load
1.5 1.5 1.5 1.5 1.5 0.7 0.7 0.7 0.7 0.7
Fan
Diameter
Inches
22 22 22 22 24 22 22 22 24 24
Fan Motor
Rated
HP
1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4
Nominal
RPM
850 850 850 850 850 850 850 850 850 850
Nominal
CFM
3100 3150 3550 3550 3600 3100 3150 3550 3550 3600
Coil
Face
Area
Sq.
Ft.
15.72 15.72 23.60 24.00 27.00 15.72 15.72 23.60 24.00 27.00
Rows
Deep
1 1 1 1 1 1 1 1 2 2
Fin
/
Inches
22 22 22 22 22 22 22 22 18 18
Liquid Line Set OD (Field Installed)
3/8
3/8
3/8
3/8
3/8
3/8
3/8
3/8
3/8
3/8
Vapor Line Set OD (Field Installed)
3/4
7/8
7/8
7/8
1-1/8
3/4
7/8
7/8
7/8
1-1/8
Unit Charge (Lbs. - Oz.)
5
5 - 13
6 - 0
8 - 13
8 - 6
10 - 2
5 - 13
6 - 0
8 - 13
8 - 6
10 - 2
Charge
Per
Foot,
Oz.
0.68 0.70 0.70 0.70 0.76 0.68 0.70 0.70 0.70 0.76
Operating
Weight
Lbs.
208 208 208 215 294 208 208 215 250 294
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
5. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than
15 feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.
C
A
B
DIMENSIONS
Unit
Model
Dimensions
(Inches)
Refrigerant Connection
Service Valve Size
A
1
1. Including Fan Guard.
* Adapter fitting required for 1-1/8” line set.
B
C
Liquid
Vapor
030
27
37
27
3/8”
3/4”
036
27
37
27
7/8”
042
39
37
27
048
34
43
32
060
38
43
32
7/8”*
