York H*RD018 THRU 060 - Manual (Page 3)

254892-YTG-C-0606
Unitary Products Group 3
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase
Outdoor Unit H2RD018S06 H2RD024S06 H2RD030S06 H2RD036S06 H2RD042S06 H2RD048S06 H2RD060S06
Required TXV 1TVM2A1 1TVM2(A,B)1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1
Factory R-22 Charge, lbs-oz 4 - 9 6 - 3 5 - 13 6 - 0 8 - 13 8 - 6 10 - 2
Indoor Coil 1,2 TXV KIT 3 - Additional Charge, Oz
FC/MC/PC/UC/UC18A2A 0 – – – – – –
FC/MC/PC/UC18B2A 0 – – – – – –
FC/MC/PC/UC24A2A 0 0 – – – – –
FC/MC/PC/UC24B2A 0 0 – – – – –
FC/MC/PC/UC30A2A – 0 0 – – – –
FC/MC/PC/UC30B2A – 0 0 – – – –
FC/MC/PC/UC36A2A – – 0 0 – – –
FC/MC/PC/UC36B2A – – 0 0 – – –
FC/MC/PC/UC36C2A – – 0 0 – – –
FC/MC/PC/UC42B2C – – – – 0 – –
FC/MC/PC/UC42C2C – – – – 0 – –
FC/MC/PC/UC48C2C – – – – 0 0 –
FC/MC/PC/UC48D2C – – – – 0 0 –
FC/PC/UC/UC60C2C – – – – – – 0
FC/MC/PC/UC60D2C – – – – – – 0
MC61D2C – – – – – – 0
HC18A2A 0 – – – – – –
HC30A2A – 0 0 – – – –
HC36B2A – – 0 0 – – –
HC42C2C – – – – 0 0 –
HC60C2C – – – – – 0 0
HD24A2A 0 0 – – – – –
HD36B2A – – 0 0 – – –
HD48C2C – – – – 0 0 –
HD60D2C – – – – – 0 0
AHP18B2A 0 – – – – – –
AHP24B2A 0 0 – – – – –
AHP30B2A – 0 0 – – – –
AHP36C2A – – 0 0 – – –
AHP42C2C – – – – 0 – –
AHP/SHP48D2C – – – – 0 0 –
AHP/SHP60D2C – – – 0 0 0 0
AV24B2A 0 0 – – – –
AV36C2A – – 0 0 – – –
AV/SV48D2C – – – – 0 0 –
AV/SV60D2C – – – – 0 0 0
FC/MC/PC/UC18A3X 0 2B + 1 – – – – –
FC/MC/PC/UC18B3X 0 2B + 1 – – – – –
FC/MC/PC/UC24A3X 0 2A + 0 – – – – –
FC/MC/PC/UC24B3X 0 2A + 0 – – – – –
FC/MC/PC/UC30A3X – 2A + 0 0 – – – –
FC/MC/PC/UC30B3X – 2A + 0 0 – – – –
FC/MC/PC/UC36A3X – – 0 0 – – –
FC/MC/PC/UC36B3X – – 0 0 – – –
FC/MC/PC/UC36C3X – – 0 0 – – –
FC/MC/PC/UC42B3X – – – – 0 – –
FC/MC/PC/UC42X3X – – – – 0 – –
FC/MC/PC/UC48C3X – – – – 0 0 –
FC/MC/PC/UC48D3X – – – – 0 0 –
FC/PC/UC/UC60C3X – – – – – – 0
FC/MC/PC/UC60D3X – – – – – – 0
MC61D3X – – – – – – 0
For Notes See Page 5.
