York H*RD018 THRU 060 - Manual (Page 4)

254892-YTG-C-0606
4 Unitary Products Group
HC18A3X 0 2B + 1 – – – – –
HC30A3X – 2A + 0 0 – – – –
HC36B3X – – 0 0 – – –
HC42C3X – – – – 0 0 –
HC60C3X – – – – – 0 0
HD24A3X 0 2A + 0 – – – – –
HD36B3X – – 0 0 – – –
HD48C3X – – – – 0 0 –
HD60D3X – – – – – 0 0
AHP18B3X 0 – – – – – –
AHP24B3X 0 2A + 0 – – – – –
AHP30B3X – 2A + 0 0 – – – –
AHP36C3X – – 0 0 – – –
AHP42C3X – – – – 0 – –
AHP/SHP48D3X – – – – 0 0 –
AHP/SHP60D3X – – – 0 0 0 0
AV24B3X 0 2A + 0 – – – –
AV36C3X – – 0 0 – – –
AV/SV48D3X – – – – 0 0 –
AV/SV60D3X – – – – 0 0 0
G2FD024(S,H)14,17 0 2B + 1 – – – – –
G2FD030(S,H)17 0 2B + 1 – – – – –
G2FD035(S,H)14 0 2B + 1 – – – – –
G2FD036(S,H)17 – 2A + 0 0 0 – – –
G2FD036(S,H)21 – – – 0 – – –
G2FD042(S,H)21 – – – 0 0 – –
G2FD046(S,H)17 – – – 0 0 – –
G2FD048(S,H)21,24 – – – – 0 0 –
G2FD060(S,H)24 – – – – – – 0
G2FD061H24 – – – – – – 0
G1HA024H14 0 2B + 1 – – – – –
G1HA036H14 – 2A + 0 0 – – – –
G1HA036H17 – 2A + 0 0 0 – – –
G1HA048H21 – – – 0 0 0 –
G1HA060H24 – – – – – 0 0
G1HD036 0 2A + 0 0 0 – – –
G1HD048 – – – 0 – – –
G1HD060 – – – – 0 0 –
G1NA030S17K 0 2B + 1 – – – – –
G1NA030S21M 0 2B + 1 – – – – –
G1NA036S17J 0 2A + 0 0 – – – –
G1NA036S21C 0 2A + 0 0 – – – –
G1NA036S17L – 2A + 0 0 0 – – –
G1NA042S24W – – – 0 – – –
G1NA048S21D – 2A + 0 0 0 – – –
G1NA060S24T – – – – 0 0 –
G1FA/G1UA030S14 0 2B + 1 – – – – –
G1FA/G1UA036S14 0 2A + 0 0 – – – –
G1FA/G1UA036S17,21 0 2B + 1 – – – – –
G1FA/G1UA048S17 – – – 0 0 – –
G1FA/G1UA048S21 – – – 0 0 – –
G1FA/G1UA060S21,24 – – – – – – 0
F2RP/F2FP024 0 2B + 1 – – – – –
F2RP/F2FP030 – 2A + 0 – – – – –
F2RP/F2FP036 – – 0 – – – –
For Notes See Page 5.
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase (Continued)
Outdoor Unit H2RD018S06 H2RD024S06 H2RD030S06 H2RD036S06 H2RD042S06 H2RD048S06 H2RD060S06
Required TXV 1TVM2A1 1TVM2(A,B)1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1
Factory R-22 Charge, lbs-oz 4 - 9 6 - 3 5 - 13 6 - 0 8 - 13 8 - 6 10 - 2
Indoor Coil
1,2
TXV KIT
3
- Additional Charge, Oz
