254892-YTG-C-0606
Unitary Products Group 5
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and for 15 feet of inter-
connecting
line tubing.
2. Verify the TXV and additional charge required for specific evaporator coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for
evaporator + adder for line set.
F2RP/F2FP040 – – – 0 – – –
F2FP048 – – – – 0 – –
F2FP060 – – – – – 0* –
F2FV060 – – – – – 0 0
G4FA030S14T2A 0 – – – – – –
G4FA030S14T2B – 1 – – – – –
G4FA036S14T2A 0 0 0 – – – –
G4FA036S17T2A 0 – – – – – –
G4FA036S21T2A 0 – – – – – –
G4FA036S21T2B – 1 – – – – –
G4FA048S17T2A – – – 0 – – –
G4FA048S17T2C – – – 0 – –
G4FA048S21T2A – – – 0 – – –
G4FA048S21T2C – – – – 0 – –
G4FA060S21T2C – – – – – – 0
G4FA060S24T2C – – – – – – 0
G4FD024H14T2A 0 – – – – – –
G4FD024H14T2B – 1 – – – – –
G4FD024H17T2A 0 – – – – – –
G4FD024H17T2B 1 – – – – –
G4FD030H17T2A 0 – – – – – –
G4FD035H14T2A 0 – – – – – –
G4FD036H17T2A – 0 0 0 – – –
G4FD036H21T2A – – – 0 – – –
G4FD042H21T2A – – – 0 – – –
G4FD042H21T2C – – – – 0 – –
G4FD046H17T2A – – – 0 – – –
G4FD046H17T2C – – – – 0 – –
G4FD048H21T2A – – – – – – –
G4FD048H21T2C – – – – 0 0 –
G4FD048H24T2A – – – – – – –
G4FD048H24T2C – – – – 0 0 –
G4FD060H24T2C – – – – – – 0
G4FD061H24T2C – – – – – – 0
F4FP024H06T2A 0 – – – – – –
F4FP024H06T2B – 1 – – – – –
F4FP030H06T2A – 0 – – – – –
F4FP036H06T2A – – – – – – –
F4FP040H06T2A – – 0 – – – –
F4FP042H06T2A – – – 0 – – –
F2FP048H06T2C – – – – 0 – –
F2FP060H06T2C – – – – – 0* –
F2FV060H06T2C – – – – – 0 0
FOOTNOTES:
1. Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.
2. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.
3. A TXV kit must be used with these coils to obtain system performance (2A, 2B, and 2C indicate 1TVM series).
* This loose coil match does not achieve 13 SEER.
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase (Continued)
Outdoor Unit H2RD018S06 H2RD024S06 H2RD030S06 H2RD036S06 H2RD042S06 H2RD048S06 H2RD060S06
Required TXV 1TVM2A1 1TVM2(A,B)1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1
Factory R-22 Charge, lbs-oz 4 - 9 6 - 3 5 - 13 6 - 0 8 - 13 8 - 6 10 - 2
Indoor Coil
1,2
TXV KIT
3
- Additional Charge, Oz
