254892-YTG-C-0606
22 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
* = Single-phase outdoor units only.
* = Single-phase outdoor units only.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H2RD048S06, H1RD048S(25,46) **
INDOOR COIL MODEL NO. FC/MC/PC/UC48
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1400 1600 1800
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 45.9 49.0 47.2 51.9 54.5 48.7 50.8 48.2 52.9 54.7 51.5 52.5 49.2 53.9 54.9
S.C. 44.2 41.8 34.6 34.7 27.5 45.8 44.4 36.9 36.9 28.2 47.5 47.0 39.2 39.0 29.0
KW 2.6 2.6 2.6 2.7 2.7 2.6 2.6 2.6 2.7 2.7 2.6 2.6 2.6 2.7 2.7
75
T.C. 44.6 47.5 45.7 50.3 52.8 47.4 48.9 46.5 51.0 53.0 50.1 50.4 47.4 51.7 53.2
S.C. 42.9 41.2 34.0 34.2 26.9 44.5 43.7 36.2 36.3 28.0 46.1 46.1 38.5 38.4 29.0
KW 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
85
T.C. 43.3 45.9 44.1 48.7 51.1 46.0 47.1 44.9 49.1 51.3 48.8 48.2 45.6 49.6 51.6
S.C. 41.6 40.6 33.4 33.7 26.4 43.1 42.9 35.6 35.7 27.7 44.6 45.2 37.7 37.8 28.9
KW 3.3 3.3 3.3 3.4 3.4 3.3 3.3 3.3 3.4 3.4 3.3 3.3 3.3 3.4 3.4
95
T.C. 42.0 44.4 42.6 47.1 49.3 44.7 45.2 43.2 47.0 49.7 47.4 46.1 43.8 47.5 50.0
S.C. 40.4 39.9 32.8 33.1 25.9 41.8 42.1 34.9 35.1 27.4 43.1 44.3 37.0 37.2 28.9
KW 3.7 3.7 3.6 3.7 3.7 3.7 3.7 3.7 3.7 3.7 3.7 3.7 3.7 3.7 3.7
105
T.C. 40.5 42.5 40.5 44.7 46.4 43.1 43.5 41.1 44.8 46.7 45.6 44.4 41.7 45.0 47.0
S.C. 38.7 38.5 31.8 32.2 24.9 40.0 40.4 33.9 34.2 26.4 41.4 42.3 36.0 36.3 27.8
KW 4.2 4.2 4.1 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2
115
T.C. 39.1 40.7 38.4 42.3 43.5 41.5 41.7 39.0 42.5 43.8 43.9 42.8 39.7 42.6 44.1
S.C. 37.2 37.2 30.8 31.2 24.0 38.4 38.7 32.9 33.3 25.4 39.6 40.3 35.0 35.4 26.8
KW 4.7 4.6 4.6 4.7 4.7 4.7 4.7 4.6 4.7 4.7 4.7 4.7 4.6 4.7 4.7
125
T.C. 37.7 38.8 36.3 40.0 40.7 39.9 40.0 37.0 40.1 40.9 42.1 41.2 37.6 40.3 41.2
S.C. 35.6 35.8 29.9 30.3 23.1 36.7 37.0 32.0 32.4 24.4 37.9 38.3 34.0 34.5 25.8
KW 5.2 5.1 5.1 5.2 5.2 5.2 5.1 5.1 5.2 5.2 5.2 5.2 5.1 5.2 5.2
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
**
For three-phase, decrease T.C. by 1.0 and S.C. by 0.7.
Air Handler Coil T.C. S.C. KW
MA12C MC48C 1.01 1.02 1.01
MA20D MC48D 1.00 1.00 1.00
MA12C G*FD048H21 1.01 1.02 1.01
MA20D G*FD048H24 1.00 1.00 1.00
AHP/SHP48 – 1.00 1.05 1.00
F*FV060* – 1.01 1.05 1.01
AHP/SHP60 – 1.01 1.03 1.01
MV16C* FC/MC48C 1.00 0.99 1.00
MV20D* FC/MC48D 1.00 0.99 1.00
AV/SV48* – 1.00 0.99 1.00
– HC48 0.99 1.00 0.99
– HD48 1.00 0.99 1.00
– G*FD048H21,24 1.00 1.00 1.00
Variable Speed
Furnace *
Coil T.C. S.C. KW
PV8*C16 FC/MC/PC48C 0.99 0.97 0.99
PV8*C20 FC/MC/PC48C 1.00 1.00 1.00
P(C,V)9*C16 FC/MC/PC48C 1.00 1.00 1.00
P(C,V)9*C20 FC/MC/PC48C 1.00 1.00 1.00
P(C,V)9*D20 FC/MC/PC48D 1.00 1.00 1.00
PV8*C16 HC48 0.99 0.97 0.99
PV8*C20 HC48 1.00 1.00 1.00
P(C,V)9*C16 HC48 0.99 1.00 0.99
P(C,V)9*C20 HC48 0.99 1.00 0.99
PV8*C16 HD48 1.01 0.99 1.01
PV8*C20 HD48 1.01 1.02 1.01
P(C,V)9*C16 HD48 1.01 1.02 1.01
P(C,V)9*C20 HD48 1.01 1.02 1.01
P(C,V)9*D20 HD48 1.01 1.02 1.01
