254892-YTG-C-0606

2

Unitary Products Group

All dimensions are in inches. They are subject to change
without notice. Certified dimensions will be provided upon
request.

PHYSICAL AND ELECTRICAL DATA - 1 PHASE

MODEL

H2RD018S06 H2RD024S06 H2RD030S06 H2RD036S06 H2RD042S06 H2RD048S06 H2RD060S06

Unit Supply Voltage

208-230V, 1

φ, 60Hz

Normal Voltage Range

1

187 to 252

Minimum Circuit Ampacity

9.4

11.8

15.1

18.3

18.3

30.3

32.7

Max. Overcurrent Device Amps

2

15

20

25

30

30

50

50

Min. Overcurrent Device Amps

3

15

15

20

20

20

35

35

Compressor Type

4

Recip

Recip

Recip

Recip

Recip

Scroll

B

Scroll

B

Compressor
Amps

Rated Load

6.4

9.0

10.7

13.4

13.5

23.0

25.0

Locked Rotor

36

48

61

78

78

115

150

Crankcase Heater

No

No

No

No

No

No

No

Fan Motor Amps Rated Load

0.8

0.5

1.5

1.5

1.5

1.5

1.5

Fan Diameter Inches

18

22

22

22

22

24

24

Fan Motor

Rated HP

1/8

1/15

1/4

1/4

1/4

1/4

1/4

Nominal RPM

1075

850

850

850

850

850

850

Nominal CFM

2150

2,200

3100

3150

3550

3550

3600

Coil

Face Area Sq. Ft.

11.43

15.72

15.72

15.72

23.60

24.00

27.00

Rows Deep

1

1

1

1

1

1

1

Fin / Inches

22

18

22

22

22

22

22

Liquid Line OD (Field Installed)

3/8

3/8

3/8

3/8

3/8

3/8

3/8

Vapor Line OD (Field Installed)

3/4

3/4

3/4

7/8

7/8

7/8

1-1/8

Unit Charge (Lbs. - Oz.)

5

4 - 9

5 - 8

5 - 13

6 - 0

8 - 13

8 - 6

10 - 2

Charge Per Foot, Oz.

0.68

0.68

0.70

0.70

0.70

0.70

0.76

Operating Weight Lbs.

151

151

183

183

193

215

220

1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
5. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15

feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.

C

A

B

DIMENSIONS

Unit

Model

Dimensions

(Inches)

Refrigerant Connection

Service Valve Size

A

1

1. Including Fan Guard.
* Adapter fitting required for 1-1/8” line set.

B

C

Liquid

Vapor

018

23

35

23

3/8”

3/4”

024

27

37

27

030

27

37

27

036

27

37

27

7/8”

042

39

37

27

048

34

43

32

060

38

43

32

7/8”*
