GS-3012/GS-3012F User’s Guide
275
C
H A P T E R
37
Product Specifications
The following tables summarize the Switch’s hardware and firmware features.
Table 109 Hardware Specifications
SPECIFICATION DESCRIPTION
Dimensions Standard 19” rack mountable
GS-3012F: 438 mm (W) x 225 mm (D) x 45 mm (H)
GS-3012: 438 mm (W) x 300 mm (D) x 45 mm (H)
Weight GS-3012F: 3.1 Kg
GS-3012: 4 Kg
Power Specification One Backup Power Supply (BPS) connector
GS-3012F
AC: 100-240 VAC 50/60 Hz, 1.5 A Max.
DC: -48 VDC ~ -60 VDC, 1.25 A Max.
GS-3012
AC: 100-240 VAC 50/60 Hzx 1.5 A Max.
DC: -48 VDC ~ -60 VDC, 1.5 A Max.
Note: There is no tolerance for the DC input voltage
Power Consumption GS-3012 AC unit: 50W maximum
GS-3012 DC unit: 48W maximum
GS-3012F AC unit: 36W maximum
GS-3012F DC unit: 38W maximum
Interfaces GS-3012F: 8 mini-GBIC (SFP) slots
GS-3012: 8 10/100/1000 Base-Tx ports
All Models: 4 GbE Dual Personality interfaces (Each interface has one
1000BASE-T RJ-45 port and one Small Form-Factor Pluggable (SFP) slot,
with one port active at a time.)
One local management RJ-45 port
Auto-negotiation
Auto-MDIX
One console port
Compliant with IEEE 802.3ad/u/x
Back pressure flow control for half duplex
Flow control for full duplex (IEEE 802.3x)
LEDs Per switch: BPS, PWR, SYS, ALM
Per Gigabit RJ-45 port/Mini-GBIC slot: 100, 1000, LNK, ACT
Per mini-GBIC slot: LNK, ACT
Per Management port: 10, 100
Operating Environment Temperature: 0º C ~ 45º C (32º F ~ 113º F)
Humidity: 10 ~ 90% (non-condensing)
