Chapter 25 Two Rate Three Color Marker
GS-3012/GS-3012F User’s Guide
211
Active Select this to activate trTCM on the port.
Commit
Rate
Specify the Commit Information Rate (CIR) for this port.
Peak
Rate
Specify the Peak Information Rate (PIR) for this port.
DSCP Use this section to specify the DSCP values that you want to assign to packets based on
the color they are marked via trTCM.
green Specify the DSCP value to use for packets with low packet loss priority.
yellow Specify the DSCP value to use for packets with medium packet loss priority.
red Specify the DSCP value to use for packets with high packet loss priority.
Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses these
changes if it is turned off or loses power, so use the Save link on the top navigation panel to
save your changes to the non-volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Table 78 Advanced Application > trTCM (continued)
LABEL DESCRIPTION
