Chapter 25 Two Rate Three Color Marker
GS-3012/GS-3012F User’s Guide
210
25.2.3 Configuring Two Rate Three Color Marker Settings
Use this screen to configure trTCM settings. Click the Advanced Application > trTCM to
display the screen as shown next.
"
You cannot enable both trTCM and Bandwidth Control at the same time.
Figure 120 Advanced Application > trTCM
The following table describes the labels in this screen.
Table 78 Advanced Application > trTCM
LABEL DESCRIPTION
Active Select this to activate trTCM (Two Rate Three Color Marker) on the Switch. The Switch
evaluates and marks the packets based on the trTCM settings.
Mode Select color-blind to have the Switch treat all incoming packets as uncolored. All incoming
packets are evaluated against the CIR and PIR.
Select color-aware to treat the packets as marked by some preceding entity. Incoming
packets are evaluated based on their existing color. Incoming packets that are not marked
proceed through the Switch.
Port This field displays the index number of a port on the Switch.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports. Use this row first
to set the common settings and then make adjustments on a port-by-port basis.
Note: Changes in this row are copied to all the ports as soon as you make
them.
