ZyWALL 5/35/70 Series User’s Guide

Chapter 37 DMZ Setup

534

37.3.2 IP Alias Setup

You must use menu 5.2 to configure the first network. Move the cursor to the Edit IP Alias
field, press [SPACE BAR] to choose Yes and press [ENTER] to configure the second and
third network.

Pressing [ENTER] opens Menu 5.2.1 - IP Alias Setup, as shown next.

Figure 293 Menu 5.2.1: IP Alias Setup

Menu 5.2.1 - IP Alias Setup

IP Alias 1= No
IP Address= N/A
IP Subnet Mask= N/A
RIP Direction= N/A
Version= N/A
Incoming protocol filters= N/A
Outgoing protocol filters= N/A
IP Alias 2= No
IP Address= N/A
IP Subnet Mask= N/A
RIP Direction= N/A
Version= N/A
Incoming protocol filters= N/A
Outgoing protocol filters= N/A

Enter here to CONFIRM or ESC to CANCEL:

Refer to

Table 199 on page 526

for instructions on configuring IP alias parameters.
