ZyXEL Communications Internet Security Appliance ZyWALL5UTM 4.0 - Manual (Page 161)

ZyWALL 5/35/70 Series User’s Guide
161 Chapter 8 DMZ Screens
8.3 DMZ Static DHCP
This table allows you to assign IP addresses on the DMZ to specific individual computers
based on their MAC Addresses.
Every Ethernet device has a unique MAC (Media Access Control) address. The MAC address
is assigned at the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
To change your ZyWALL’s static DHCP settings on the DMZ, click NETWORK, DMZ and
then the Static DHCP tab. The screen appears as shown.
Allow between DMZ
and WLAN
Select this check box to forward NetBIOS packets from the WLAN to the DMZ
and from the DMZ to the WLAN.
Clear this check box to block all NetBIOS packets going from the WLAN to the
DMZ and from the DMZ to the WLAN.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 45 DMZ (continued)
LABEL DESCRIPTION
