ZyXEL Communications 802.11g Wireless Firewall Router P-320W - Manual (Page 163)

P-320W User’s Guide
Appendix A Product Specifications 163
A
P P E N D I X
A
Product Specifications
See also the Introduction chapter for a general overview of the key features.
Specification Tables
Table 69 Device
Default IP Address 192.168.1.1
Default Subnet Mask 255.255.255.0 (24 bits)
Default Password 1234
DHCP Pool 192.168.1.32 to 192.168.1.64
Dimensions (181 W) x (128 D) x (36 H) mm
Weight 424g
Power Specification 12VAC
Built-in Switch Four auto-negotiating, auto MDI/MDI-X 10/100/1000 Mbps RJ-45 Ethernet
ports
Operation Temperature 0º C ~ 65º C
Storage Temperature -20º ~ 60º C
Operation Humidity 15% ~ 90% RH
Storage Humidity 10% ~ 90% RH
Table 70 Firmware
Standards IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
TCP, UDP, ICMP, ARP, RIP - 1/RIP - 2
IP Routing (RFC 791)
PPP over Ethernet (RFC 2516)
MAC encapsulated routing (ENET encapsulation)
Other Protocol Support PPP (Point-to-Point Protocol) link layer protocol.
DHCP Server (RFC 2131, 2132)
RIP I/RIP II
ICMP
SNMP v1 and v2c with MIB II support (RFC 1213)
UPnP
Management Embedded Web Configurator
Remote Management via Web
SNMP manageable
Configuration backup and restoration.
Built-in Diagnostic Tools for FLASH memory, RAM and LAN port
Syslog
