Prestige 660RU-Tx Series User’s Guide

Chapter 24 System Information and Diagnosis

204

Figure 141 Menu 24.4 System Maintenance : Diagnostic

The following table describes the diagnostic tests available in menu 24.4 for and the
connections.

Menu 24.4 - System Maintenance - Diagnostic

xDSL System
1. Reset xDSL 21. Reboot System
22. Command Mode

TCP/IP
12. Ping Host

Enter Menu Selection Number:

Host IP Address= N/A

Table 64 Menu 24.4 System Maintenance Menu: Diagnostic

FIELD

DESCRIPTION

Reset xDSL

Re-initialize the xDSL link to the telephone company.

Ping Host

Ping the host to see if the links and TCP/IP protocol on both systems are working.

Reboot System

Reboot the Prestige.

Command Mode

Type the mode to test and diagnose your Prestige using specified commands.

Host IP Address

If you typed 12 to Ping Host, now type the address of the computer you want to

ping.
