Chapter 18 Remote Node Configuration
152
Figure 83 Menu 11.6 for VC-based Multiplexing
18.5.2 LLC-based Multiplexing or PPP Encapsulation
For LLC-based multiplexing or PPP encapsulation, one VC carries multiple protocols with
protocol identifying information being contained in each packet header.
Figure 84 Menu 11.6 for LLC-based Multiplexing or PPP Encapsulation
In this case, only one set of VPI and VCI numbers need be specified for all protocols. The
valid range for the VPI is 0 to 255 and for the VCI is 32 to 65535 (1 to 31 is reserved for local
management of ATM traffic).
18.5.3 Advance Setup Options
In menu 11.1, select PPPoE in the Encapsulation field.
Menu 11.6 - Remote Node ATM Layer Options
VPI/VCI (VC-Multiplexing)
VC Options for IP: VC Options for Bridge:
VPI #= 8 VPI #= 1
VCI #= 35 VCI #= 36
ATM QoS Type= UBR ATM QoS Type= N/A
Peak Cell Rate (PCR)= 0 Peak Cell Rate (PCR)= N/A
Sustain Cell Rate (SCR)= 0 Sustain Cell Rate (SCR)= N/A
Maximum Burst Size (MBS)= 0 Maximum Burst Size (MBR)= N/A
Press ENTER to Confirm or ESC to Cancel:
Menu 11.6 - Remote Node ATM Layer Options
VPI/VCI (LLC-Multiplexing or PPP-Encapsulation)
VPI #= 8
VCI #= 35
ATM QoS Type= UBR
Peak Cell Rate (PCR)= 0
Sustain Cell Rate (SCR)= 0
Maximum Burst Size (MBS)= 0
ENTER here to CONFIRM or ESC to CANCEL:
