Prestige 660RU-Tx Series User’s Guide

Chapter 22 Filter Configuration

188

Figure 125 Sample Telnet Filter

1 Enter 21 in the main menu to display Menu 21 — Filter Set Configuration.

2 Enter the index number of the filter set you want to configure (in this case 6)

.

3 Type a descriptive name or comment in the Edit Comments field (for example,

TELNET_WAN) and press [ENTER].

4 Press [ENTER] at the message

Press [ENTER] to confirm or [ESC] to

cancel ...

” to open Menu 21.6 — Filter Rules Summary.

5 Type 1 to configure the first filter rule. Make the entries in this menu as shown next.

When you press [ENTER] to confirm, the following screen appears. Note that there is only
one filter rule in this set.
