Chapter 4 The Web Configurator
XGS-4528F User’s Guide
56
The following table describes the links in the navigation panel.
Table 6 Navigation Panel Links
LINK DESCRIPTION
Basic Settings
System Info This link takes you to a screen that displays general system and hardware
monitoring information.
General Setup This link takes you to a screen where you can configure general identification
information and time settings for the Switch.
Switch Setup This link takes you to a screen where you can set up global Switch parameters
such as VLAN type, MAC address learning, IGMP snooping, GARP and priority
queues.
IP Setup This link takes you to a screen where you can configure the IP address, subnet
mask (necessary for Switch management) and DNS (domain name server) and set
up to 64 IP routing domains.
Port Setup This link takes you to screens where you can configure speed, flow control and
priority settings for individual Switch ports.
Advanced Application
VLAN This link takes you to screens where you can configure port-based or 802.1Q
VLAN (depending on what you configured in the Switch Setup menu). You can also
configure a protocol based VLAN or a subnet based VLAN in these screens.
Static MAC
Forwarding
This link takes you to screens where you can configure static MAC addresses for a
port. These static MAC addresses do not age out.
Filtering This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure the RSTP/MRSTP/MSTP to
prevent network loops.
Bandwidth
Control
This link takes you to screens where you can cap the maximum bandwidth allowed
from specified source(s) to specified destination(s).
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring This link takes you to screens where you can copy traffic from one port or ports to
another port in order that you can examine the traffic from the first port without
interference.
Link Aggregation This link takes you to screen where you can logically aggregate physical links to
form one logical, higher-bandwidth link.
Port
Authentication
This link takes you to a screen where you can configure IEEE 802.1x port
authentication as well as MAC authentication for clients communicating via the
Switch.
Port Security This link takes you to a screen where you can activate MAC address learning and
set the maximum number of MAC addresses to learn on a port.
Classifier This link takes you to a screen where you can configure the Switch to group
packets based on the specified criteria.
Policy Rule This link takes you to a screen where you can configure the Switch to perform
special treatment on the grouped packets.
Queuing Method This link takes you to a screen where you can configure queuing with associated
queue weights for each port.
VLAN Stacking This link takes you to a screen where you can activate and configure VLAN
stacking.
Multicast This link takes you to screen where you can configure various multicast features
and create multicast VLANs.
