Chapter 22 Multicast
XGS-4528F User’s Guide
181
Figure 86 MVR Multicast Television Example
22.7 General MVR Configuration
Use the MVR screen to create multicast VLANs and select the receiver port(s) and a source
port for each multicast VLAN. Click Advanced Applications > Multicast > Multicast
Setting > MVR link to display the screen as shown next.
"
You can create up to three multicast VLANs and up to 256 multicast rules on
the Switch.
"
Your Switch automatically creates a static VLAN (with the same VID) when
you create a multicast VLAN in this screen.
