Clearing clogged jets
Clogged jets can not be automatically detected and therefore you must manually clear them. Only clear them after
you have tried to clean them using the procedures on the previous page.
1 Press Utility Menu/Calibration Menu/Open Jet Menu/Edit List Menu and press the Edit List button that
designates the color of the cartridge of interest.
2 To compensate for a specific jet, press Next / Prev until the number of the jet is displayed. Then press the Jet
button to toggle the jet’s status On or Off.
3 Press OK to accept the settings.
4 To check jet status press Utility Menu/Calibration Menu/Open Jet Menu/Print Jet List. The jet status list will
print, showing jet compensation list by number for each cartridge.
