Weil-McLain GV90+ - Manual (Page 94)

Part number 550-142-054/0411
GV90+
gas
-
fired water boiler
— Boiler Manual
94
Figure 101 Blower assembly
Item
number Description Model Weil-McLain
part number
1 Burner replacement kit, includes burner, blower flange gasket, igniter, igniter
screws, igniter washers, igniter gasket
3
4
5
6
382-200-320
382-200-325
382-200-330
382-200-335
2 Blower flange gasket All 590-317-610
3 Air pressure switch (0 to 5,500 feet elevation) All 382-200-723
— Air pressure switch (5,500 to 10,000 feet elevation) All Consult W-M factory
4 Blower motor replacement kit, includes blower motor, motor mounting
grommets, screws, lock nuts and 9" Allen wrench
All 382-200-345
5 Blower housing assembly replacement kit, includes: blower housing, obsv.
port, blower housing cover plate, blower motor mounting brackets, washer hold
down bracket, lock nuts, motor mount grommets, blower motor, blower wheel,
magnetic washer, silicone sealant, screws, blower flange gasket, igniter, igniter
washers, igniter screws, igniter gasket
All 382-200-340
6 Conversion kit, natural to propane, includes . . . . . . . . . . . . . . . . . . . . . .
Propane orifice plate, label
3
4
5
6
510-811-926
510-811-927
510-811-928
510-811-929
Orifice plate, natural gas . . . . . . . . . . . . . . . . . . . . . . 3
4
5
6
510-811-934
510-811-935
510-811-936
510-811-937
7 Gas/air manifold assembly, includes gas/air manifold, gas tubing, washers,
screws, gas valve o-ring
All 382-200-362
8 Sense line condensate trap, includes sense line condensate trap and hoses All 382-200-409
10 Gas valve kit, complete, includes gas valve, gas cock, 1/2" nipple, bracket, o-ring,
screws
All 382-200-411
12 Igniter replacement kit, includes igniter and gasket All 511-330-148
13 Igniter gasket All 590-317-599
14 Inlet air tube w/grill All 382-200-310
15 Hose clamp, 3” All 591-850-068
16 Inlet air hose, 3" by 19" long All 562-302-573
17 & 18 Inspection port cover and Inspection port gasket All see Figure 97, page 90
items 10 and 11
19 Recuperator connection gasket All see item 24
20 Condensate drain hose clamp All —
21 Condensate trap All 560-907-716
22 ½” PVC condensate tee All —
23 Condensate tee U-clamp All —
24 Recuperator kit, includes recuperator, recuperator connection gasket, diamond
flange gasket (2), connection hardware (4-nuts), flue gas thermal fuse
3 and 4
5 and 6
382-200-714
382-200-715
25 Diamond flange, 1” npt All see item 24
26 Diamond flange gasket All 590-317-535
27 Flue gas thermal fuse All 511-724-295
28 In-line flue adapter with drain kit, includes in-line flue adapter with drain and
drain hose (6 inches)
All 382-200-716
29 Flue drain hose kit, 6 inches All 382-200-717
30 Recuperator cover plate 3 and 4
5 and 6
593-000-002
593-000-003
31 Recuperator cover plate gasket 3 and 4
5 and 6
593-000-004
593-000-005
32 Recuperator vent pipe seal All 593-000-006
Replacement parts
(continued)
