Page 5 O
PERATING
M
ANUAL
S
UPPLIED
A
CCESSORIES
Hand Microphone MH-31
B8
(depending on transceiver version) ......................................................................... 1
AC Power Cord (T9013282 for 100 - 120 V or T9013285 for 200 - 240 V) .......................................................... 1
Spare Fuse (8-A [Q0000104] for 100 - 120 V or 4-A [Q0000103] for 200 - 240 V) ............................................... 1
RCA Plug (P0090544) ....................................................................................................................................... 1
¼-inch 3-contact Plug (P0090008) ..................................................................................................................... 1
3.5 mm 2-contact Plug (P0090034) .................................................................................................................... 1
3.5 mm 3-contact Plug (P0091046) .................................................................................................................... 1
4-pin DIN Plug (P0091004) ................................................................................................................................ 1
5-pin DIN Plug (P0091006) ................................................................................................................................ 1
Operating Manual .............................................................................................................................................. 1
Warranty Card ................................................................................................................................................... 1
A
VAILABLE
O
PTIONS
A
CCESSORIES
& O
PTIONS
TCXO-6
H IGH -S TABILITY M ASTER R EFERENCE O SCILLATOR
For special applications and environments where
extra frequency stability is essential, such as for long-
term HF packet monitoring under wide temperature
variations, the TCXO-6 provides ±0.25-ppm stability
the master reference oscillator (after 1 min. @ 25 °C).
MD-100
A8X D ESK -T OP M ICROPHONE
Designed especially to match the electrical and cos-
metic features of the MARK-V FT-1000MP
Field, the
MD-100 A8X has a 600 Ohm impedance, and includes an
up/down scanning ring and a large PTT switch with latch.
MD-200
A8X
U LTRA -H IGH -F IDELITY D ESK -T OP M ICROPHONE
Designed especially to match the electrical and cos-
metic features of the MARK-V FT-1000MP
Field, the
MD-200 A8X includes a new-technology “Variable Side
Pressure Control” (VSPC), which allows precise ad-
justment of the microphone’s audio response without
resorting to “active” equalization circuits that can intro-
duce distortion and/or degrade signal-to-noise ratio.
VL-1000
L INEAR A MPLIFIER
The VL-1000 is an all-solid-state linear amplifier
operating on the 160 through 6 meter amateur bands
(USA version: 160-15 meters) at a power output level
of 1000 Watts on CW and SSB (500 Watts on continu-
ous data modes such as RTTY). The VL-1000 includes
a built-in antenna tuner with 240 memories for tuning
data, and microprocessor control of the tuning circuitry.
The VL-1000 features input jacks for two different
exciters, as well as four antenna jacks for connection
of antennas for different bands. Extensive self-test, sys-
tem monitoring, and protection circuits are provided,
with status and tuning information being displayed on
a huge Liquid Crystal Display panel.
The companion VP-1000 AC Power Supply provides
the necessary voltages for the 48-Volt PA section of
the VL-1000.
FTV-1000
50 MH Z T RANSVERTER &
FRB-5
R
ELAY
U
NIT
The FTV-1000 is a high-performance, high-power 50-
54 MHz transverter compatible with the MARK-V FT-
1000MP
Field. Providing excellent receiver performance
and up to 200 Watts of power output, the FTV-1000 is
specifically designed for the demanding requirements of
50 MHz DX operators. Among the leading-edge features
of the FTV-1000 is a Class-A operating bias selection for
the transmitter’s power amplifier stage; during Class-A
operation, power output is reduced to 50 Watts, and the
high bias current leads to an extraordinarily clean SSB
wave-form, with 5
th -order intermodulation (IMD) typically
suppressed by at least 65 dB.
Besides this unit, you must also purchase the FP-
29 AC Power Supply and FRB-5 Relay Unit, available
from your Yaesu dealer.
The FRB-5 Relay Unit allows interconnection and
operation of the FTV-1000 with the MARK-V FT-1000MP
Field Transceiver.
SP-8
L
OUDSPEAKER WITH
A
UDIO
F
ILTERS
&
LL-7
P HONE P ATCH O PTION
Selectable audio high- and low-pass filters together
with a large loudspeaker complement the superb au-
dio characteristics of the MARK-V FT-1000MP
Field
with your choice of 12 different audio filtering combi-
nations. Two input terminals are provided for multiple
transceivers, with a front panel switch to select between
them. A (monaural) phone jack is provided on the front
panel to take advantage of the audio filters with head-
phones.
With the optional LL-7 Phone Patch Unit installed in
the SP-8, the MARK-V FT-1000MP
Field can be patched
to the public telephone network. The LL-7 includes a
hybrid transformer circuit to assure proper impedance
matches, and front panel gain controls and level meter
to set proper audio levels on the telephone line.
