Page 17 O
PERATING
M
ANUAL
A
CCESSORY
I
NSTALLATION
D
IGITAL
M
ODEM
(TNC, W
EATHER
F
AX
,
ETC
.) I
NTERFACING
TNC
CAUTION!!
The MARK-V FT-1000MP
Field cooling system is
designed to handle continuous duty transmission
at 100 watts output. However, for continuous-duty
digital modes like RTTY, we recommend limiting
your transmissions to 3 minutes or less, with at
least 3 minutes receive in between transmissions.
Place your hand on the transceiver occasionally to
ensure that it’s not getting too hot, and try to keep
power output at 50 watts or less.
You can limit the maximum RF power output to 25
watts via programming, by recalling menu selection
4-0 and choosing reduced power output.
MARK-V FT-1000MP
Field
REMOTE
B A ANT
KEY BACKUP
LIN
CAT DVS-2
BAND DATA
+13.8V TRV TX GND RX ANT
PACKET RTTY PTT
EXT
ALC EXT
SPKR PATCH AF OUT
GND OFF
OFF IN OUT
C W
SIDETONE ON
ACC
O N
OUTPUT
DC 13.8V
200 mA
INPUT
DC 13.8V
20 A
INPUT
AC 100-120V ~
50-60Hz 6A FUSE T8A
DC IN ~ AC IN
FSK OUT PTT AF IN
RTTY RTTY JACK RTTY Machine
Pin 1
Pin 2
Pin 3
Pin 4 FSK OUT
AF IN
PTT
GND
