U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
PPPoA
Enter 3 at the SNDCP Menu. The PPPoA Menu appears. This menu provides the following
options…
●
List PPPoA. Enter 1 at the PPPoA Menu. The List PPPoA Menu appears. This menu
displays configured PPPoA variables.
●
Configure PPPoA. Enter 2 at the PPPoA Menu. The PPPoA Menu appears. This is a two-
screen menu. Set these PPPoA variables...
Configure PPPoA, Screen 1 Configure PPPoA, Screen 2
§ Profile ID [0-7] § MTU [0-1,500]
§ Interface Name [ ppp [0-7] ] § Encapsulation Type [11c/vc]
§ Vpi [0-255] § Restart Time
§ Vci [0-65,535] § My IP Address
§ User Name § Peer IP Address
§ Password § Enable Nat [Y/N]
§ Authentication Protocol
[pap/chap]
§ NetMask
§ MRU [0-1,500]
After you complete your configuration, proceed to the Basic Menu and enter 8. The Save &
Reboot Menu appears. From this menu, save your changes and reboot the router.
•
Start PPPoA. Enter 3 at the PPPoA Menu. The Start PPPoA Menu appears. This menu
allows you to start a PPPoA session by entering the session’s profile ID.
•
Stop PPPoA. Enter 4 at the PPPoA Menu. The Stop PPPoA Menu appears. This menu
allows you to stop a PPPoA session by providing the session’s profile ID.
•
Delete PPPoA. Enter 5 at the PPPoA Menu. The Delete PPPoA Menu appears. This menu
allows you to delete a PPPoA session by entering the session’s profile ID.
•
Default PPPoA. Enter 6 at the PPPoA Menu. The Default PPPoA Menu appears. This
menu allows you to make a PPPoA session the default session by providing the session’s
profile ID.
Main Menu=>Advanced=>SNDCP=>
PPPoE
