Toshiba B-852-TS12-QP - Manual (Page 42)

APPENDIX 1 SPECIFICATIONS ENGLISH VERSION EO1-33028
A1.2 Options
EA1- 2
A1.2 Options
Option Name Type Description Source
Cutter module B-7208-QM A stop and cut swing cutter. See NOTE.
PCL5 interface board B-7708-PCL-QM These boards enable the B-852 printer to support the
HP-PCL5. See NOTE.
Expansion I/O
interface board B-8700-IO-QM Installing this board in the printer allows a
connection with an external device with the
exclusive interface, such as the keyboard module. See NOTE.
Keyboard module KB-80-QM This module is an external intelligent keyboard unit,
including a 16 digit by 2 line LCD and 28 key
switches. See NOTE.
PCMCIA interface
board B-7708-PC-QM This board enables the use of the following
PCMCIA cards.
LAN card: 3 COM EtherLink® III (recommended)
ATA card: Conforming to PC card ATA standard
Flash memory card: 4MB card (See page 2-14.) See NOTE.
A1.3 Media
Please make sure that the media that will be used is approved by TOSHIBA TEC. The warranty does not apply
when a problem is caused by using media that is not approved by TOSHIBA TEC.
For information regarding TOSHIBA TEC approved media, please contact a TOSHIBA TEC authorised service
representative.
A1.3.1 Media Type
Two types of media can be loaded for this thermal transfer and direct thermal printer label or tag. The table
below shows size and shape of the media available for this printer.
NOTE:
Available from your nearest TOSHIBA TEC representative or TOSHIBA TEC Head Quarters.
Label
c
d
f
e
h
i
j
Tag paper
c
e
g
h
i
Cut position
Cut position
Stop
position
Stop
position
Feed Direction
Black Mark
(on reverse side)
Black Mark
(on reverse side) Refer to
NOTE 3 below.
