2. PRINTER SETUP ENGLISH VERSION EO1-33028
2.11 Test Print
E2-16
2.11 Test Print (Cont.) 8. Press the [PAUSE] key again and the printer will now print five
labels of sample bar codes lines and the LCD Message Display will
continue to display the following message.
9. Press the [PAUSE] key again and the printer will now print five
labels of characters of various sizes and the LCD Message Display
will return to showing the test print start message as shown below.
10. Upon pressing the [RESTART] key for the second time in step 6 ,
the LCD Message Display will change to that shown below.
11. Press the [PAUSE] key and the printer will issue one blank label
and will then print five labels of slant lines and the LCD Message
Display will continue to display the following message.
12. Press the [PAUSE] key again and the printer will now print five
labels of sample bar codes lines and the LCD Message Display will
continue to display the following message.
13. Press the [PAUSE] key again and the printer will now print five
labels of characters of various sizes and the LCD Message Display
will return to showing the test print start message as shown below.
14. If necessary, the print test may now be repeated from step 4 .
NOTE:
If an error occurs during the
print test the printer will
display an error message and
stop printing. Refer to
Chapter 6.1 for definition of
error messages.
The error may be cleared by
pressing the
[PAUSE] key but
the test print will not be
resumed and the LCD message
display will return to showing:
<1> DIAG. V1.0A
$87235,175()/
!7(6735,17
$87235,1775$1
$87235,1775$1
$87235,1775$1
!7(6735,17
NOTE:
When the [PAUSE] key is
pressed in Step 10, the printer
will enter each print pattern
detailed on the setting menu
mode. To exit, press the
[FEED] and [RESTART] keys
at the same time.
