[Connector pin assignment]
(1) Compatible connector
HR10A-10P-12S (Supplied by HIROSE ELEC.)
(2) Pin assignment
12 pin male
Connector pin layout
Picture Rear-panel camera connector
(Rear-view)
Pin
No.
Signal
(Standard)
Signal
[Option]
1 DC12V
GND
2 DC12V
3 VIDEO
GND
4 VIDEO
OUT
5 HD
GND
6 HD
IN
7 VD
IN
8 TRIG
GND
NC
9 NC TRIG
IN
10 WEN
OUT
GND
11 TRIG
IN DC12V
NC
12 VD
GND PARTIAL
Notes : *Before connecting / disconnecting the connector, make sure the camera power is OFF.
**For board connection, check compatibility.
Note: Items shown as [Option] in this document is not included in your purchase as standard
components. Contact our dealer / distributor for details.
