Page 15
1/120s 2:1 Interlace
Under 1/120s interlace mode, only the center portion of 207H out of the total effective
lines 485H (excluding BLK time) is read out. Available both under external / internal
mode.
ODD Field
EVEN Field
Under normal shutter (Electronic shutter OFF)
Notes: * Under ext. sync, the ext. VD should be 1V = 131.5H.
** Under normal shutter, set the rear-panel DIP SW #6, #7 in OFF.
73H
66.5H
High-speed
trasfer
Normal-
speed
transfer
High-speed
transfer
103H
103H
Normal-
speed
transfer
72.5H
66H
High-speed
transfer
High-speed
transfer
104H
104H
Normal-
speed
transfer
Normal-
speed
transfer
21H
103H
7H
154
155
358
359
153
154
359
360
20.5H
104H
7H
0.5H
131.5H
131.5H
ODD image
EVEN image
9H
8.5H
9H
9H
8.5H
9H
V BLK
(Include
High-speed
transfer)
VIDEO output
time
High-
speed
transfer
V BLK
(Include
High-speed
transfer)
VIDEO output
time
High-
speed
transfer
VIDEO OUT
WEN OUT
(Standard)
WEN OUT
[Option]
D4130891A
15
