1/120s 2:1 Interlace
Irrespective of TRIG IN phase, the camera always outputs ODD field image.
(4-3) MULTIPLE SHUTTER mode
Multiple shutter operation is available by providing TRIG IN more than one time before
ext. VD IN. (Non-reset mode, single VD, consecutive VD IN)
1/60s Non-interlace
1/120s 2:1 Interlace
Video output field (ODD/EVEN) is determined by ext. VD falling edge and ext. HD
phase.
ODD ODD ODD EVEN
ODD
EVEN
image ODD
ODD
TRIG IN
(Positive)
VIDEO OUT
CCD Exposure
WEN OUT
(Standard)
WEN OUT
[Option]
TRIG IN not acceptable for
1V after mode chenge
Exposure time
(E-shutter speed)
VD,V-SYNC output for 1V only
VD,V-SYNC pause during standby
Normal shutter Random trigger shutter Normal shutter
Definite
Automatically returns to normal shutter
if fixed H level (after approx. 1/6s)
Three exposures are mixed and output
here
TRIG IN
(Positive)
EXT VD
CCD Exposure
VIDEO OUT
WEN OUT
(Standard)
WEN OUT
[Option]
Exposure time
(E-shutter speed or
pulse width)
ODD
phase
ODD
EVEN
EVEN
phase
TRIG IN
(Positive)
EXT VD
CCD Exposure
VIDEO OUT
WEN OUT
(Standard)
WEN OUT
[Option]
Exposure time
(E-shutter speed or
pulse width)
Three exposures are mixed and output here
D4130891A 11
