[Electronic shutter spec]
(1)Normal shutter
Shutter-speed setting via rear-panel SW (Initial: OFF)
8 steps switch-able (= OFF, 1/200s, 1/500s, 1/1000s, 1/2000s, 1/4000s,
1/8000s, 1/20000s)
(2)RTS
(a)Operation mode
Notes : * RTS mode automatically switches over through TRIG IN
**RTS disabled under Electronic shutter OFF
(b)Multiple shutter
Multiple shutter via ext. trigger signal and ext. VD signal
Notes : * Operation like No.3, 6 above
(3)Restart / Reset
Restart / reset available via ext. VD signal
(Switching via rear panel DIP SW, Initial OFF)
Notes : * The exposure-time (shutter-speed) is determined by ext.
VD interval.
** Enabled when rear-panel DIP SW OFF.
***Provide Consecutive HD.
[Partial scan]
(1)Operation mode
Note: Items shown as [Option] in this document is not included in your purchase as
standard components. Contact our dealer / distributor for details.
No.
Reset
Exposure
Sync
1
Internal
2
Consecutive HD / Consecutive VD IN
3
Consecutive HD / Single VD IN
4
Internal
5
Consecutive HD / Consecutive VD IN
6
Consecutive HD / Single VD IN
7
Internal
8
Consecutive HD IN
9
SYNC reset
Internal
10
Internal
11
Consecutive HD IN
Rear SW
(FIX mode)
V reset
V-reset
Non-reset
Rear SW
(FIX mode)
TRIG pulse width
(PULSE width mode)
TRIG pulse width
(PULSE width mode)
No
Scan mode
Sync
Reset
E-shutter Normal
E-shutter RTS
1
Non-reset Enabled [Option]
Enabled
2
V-reset
Disabled
3
Consecutive HD VD IN
Non-reset Enabled [Option]
Enabled
4
Consecutive HD (VD) IN
V-reset
Disabled
5
Non-reset Enabled [Option]
Enabled
6
V-reset
Disabled
7
Consecutive HD VD IN
Non-reset Enabled [Option]
Enabled
8
Consecutive HD (VD) IN
V-reset
Disabled
9
Programmable
Consecutive HD VD IN
Non-reset Enabled [Option]
Enabled [Option]
Internal
1/2 partial
1/4 partial
Internal
