(5-2)1/4 Partial-scan (Rear-panel SW: #8-ON, #9-ON) --- Screen center 1/4 readout
1/60s Non-interlace
Under 1/60s non-interlace mode, only the center portion of 81H out of the total effective
lines 494H (excluding BLK time) is read out. Available both under external / internal
mode.
Under normal shutter (Electronic shutter OFF)
Notes: * Under ext. sync, the ext. VD should be 1V = 131H.
** Under normal shutter, set the rear-panel DIP SW #6, #7 in OFF.
Under other shutter modes
200H
213H
High-speed
transfer
81H
81H
Normal-
speed
transfer
Normal-
speed
transfer
High-speed
transfer
28H
81H
VIDEO OUT
Video output
time
22H
201
281
201
281
V BLK
(Include
High-speed
transfer)
131H
131H
3H
WEN OUT
(Standard)
WEN OUT
[Option]
High
-speed
transfer
3H
3H
3H
3H
3H
28H
81H
*1
22H
201
(394H)
281
3H
4H
*2
VIDEO OUT
WEN OUT
(Standard)
WEN OUT
[Option]
V BLK
(Include
High-speed
transfer)
Video output
time
High
-speed
transfer
*1:Arbitrary under ext.sync
*2:See "7.TIMING CHART (4)WEN timing".
3H
