D4130891A 24
6. SPECIFICATIONS
[Basic spec]
(1) Image sensor All Pixel’s Data Read-out Interline CCD
Total pixels 692(H) x 504(V)
Active pixel 659(H) x 494(V)
Video output pixels 648(H) x 494(V) (Under non-interlace)
Scanning area 4.88(H) x 3.66(V) mm (=Equivalent to 1/3 type CCD size)
Unit cell size 7.4(H) x 7.4(V) micro m (Square-grid array)
(2) TV system Special format (Non-conforming to EIA)
(3) Scanning lines 525 lines
(4) Interlace 1/60s Non-interlace mode
1/120s 2:1 Interlace mode
Switching via rear-panel DIP SW
(5) Sync system Internal/External automatic switch-over
(6) Aspect ratio 4:3
(7) Video output VS 1.0V(p-p) / 75 , DC coupled, 1 line (AC as [Option])
(8) Resolution 485 TV lines(H)
485 lines (350 TV lines)(V)
(9) S/N Standard: 52dB(p-p)/rms (Initial factory setting)
(10) Illumination Standard 400 lx (F5.6)
Minimum 4 lx (F1.4) (GAIN MAX, Approx. 50% video output)
(11) Gain FIX (Fixed) gain: Factory-shipped preset level
MANU (Manual) gain: Setting through GAIN VR
FIX / MANU switching via rear-panel DIP SW
(12) Gamma correction Gamma = 1 (Fixed)
(13) White-clip level Approx. 840mV(p-p) (Excluding SYNC)
(14) Power source DC12V
±10%
Ripple voltage: 50mV(p-p) or less
(15) Power consumption Approx. 1.5W
[Internal sync spec]
(1) Base clock frequency 24.545MHz (1CLK)
±200ppm
(2) H sync frequency 31.468kHz (1H = 780CLK)
(3) V sync frequency 59.94Hz (Under non-interlace)
119.88Hz (Under 2:1 interlace)
Note: Items shown as [Option] in this document is not included in your purchase as standard
components. Contact our dealer / distributor for details.
