E6581222
48
„ Inverter operating status3 (FE42, FD42)
Operating status 3(status immediately before the occurrence of a trip):
Communication Number FE42
Operating status 3(current status): Communication Number FD42
Bit Function 0 1 Remarks
0 (Reserved)
1 Electric Power Counting
(FE76,FE77) status
Counting Resetting
2 (Reserved)
3 (Reserved)
4 (Reserved)
5 (Reserved)
6 (Reserved)
7 (Reserved)
8 Acceleration/deceleration
pattern selection1
9 Acceleration/deceleration
pattern selection2
00:Acceleration/deceleration 1
01:Acceleration/deceleration 2
10:Acceleration/deceleration 3
Acceleration/ decelera-
tion 1 - 3 can be speci-
fied by combination of
two bits
10 (Reserved)
11 (Reserved)
12 Over-current stall level change OC stall 1 OC stall 2 OC1:F601
OC2:F185
13 (Reserved)
14 (Reserved)
15 (Reserved)
„ Inverter operating status4 (FE49, FD49)
Operating status 4(status immediately before the occurrence of a trip):
Communication Number FE49
Operating status 4(current status): Communication Number FD49
Bit Function 0 1 Remarks
0 RY terminal output hold OFF Holding
1 OUT terminal output hold OFF Holding
2 to 15 (Reserved)
