7. Communications parameters
The settings of communication-related parameters can be changed from the operation panel and the
external controller (computer). Note that there are two types of parameters: parameters whose set-
tings take effect immediately after the setting and parameters whose settings do not take effect until
the inverter is turned back on or reset.
Com-
munica-
tion
Number.
Title Function Adjustment range Unit
Default
setting
Valid Reference
0800 
Communication
baud rate
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
- 3 After reset. Section 7.1
0801  Parity
0: NON (No parity)
1: EVEN (Even parity)
2: ODD (Odd parity)
- 1 After reset. Section 7.1
0802  Inverter number 0-255 1 0 Real time Section 7.2
0803 
Communication
error trip time 0: (disabled)
1-100
1s 0 Real time Section 7.3
0805 
Communication
waiting time
0.00-2.00s 0.01s 0.00 Real time Section 7.4
0806 
Setting of master
and slave inverters
for communication
between inverters
(setting of master
and slave)
0: Slave inverter (0 Hz command issued
in case the master inverter fails)
1: Slave inverter (Operation continued in
case the master inverter fails)
2: Slave inverter (Emergency stop trip-
ping in case the master inverter fails)
3: Master inverter (transmission of fre-
quency commands)
4: Master inverter (transmission of output
frequency signals)
- 0 After reset. Chapter 6
0811  Point 1 setting 0-100 1% 0 Real time
0812  Point 1 frequency 0.0-500.0Hz 0.01Hz 0.0 Real time
0813  Point 2 setting 0-100 1% 100 Real time
0814  Point 2 frequency 0.0-500.0Hz 0.01Hz 60.0 Real time
Section 6.1
0829 
Selection of com-
munication proto-
col
0: Toshiba inverter protocol
1: Modbus-RTU protocol
- 0 After reset. Chapter 3
0870  Block write data 1
0871  Block write data 2
0: No selection
1: Command information 1
2: Command information 2
3: Frequency command
4: Output data on the terminal board
5: Analog output for communications
-
0
After reset.
0875  Block read data 1
0876  Block read data 2
0877  Block read data 3
0878  Block read data 4
0879  Block read data 5
0: No selection
1: Status information
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal board monitor
8: Output terminal board monitor
9: VIA terminal board monitor
10: VIB terminal board monitor
- 0
After reset.
Section
4.1.3
0880  Free notes 0-65535 1 0 Real time Section 7.5
