E6581222
15
■ Block Write 1, 2
Select data, which is desired to be written in block communications, in Block Communication Write
Data 1 and 2 Parameters (, )
.
This parameter becomes effective when the system
is reset, such as when power is turned off. When the setting is completed, turn off and then on the
power.
* When “No selection” is specified in the parameters, no data will be written even though write data is
specified.
■ Block Read 1 to 5
Select read data, which is desired to be read in block communications, in Block Communication
Read Data 1 and 5 Parameters (to).
This parameter becomes effective when
the system is reset, such as when power is turned off. When the setting is completed, turn off and
then on the power.
* Output current (FE03), output voltage (FE05) and PID feedback value (FE22) will become hold data
during a trip. Otherwise, real-time data appears.
* “0000” will be returned as dummy data,
if “0 (No selection)” is selected for the parameter and “read”
is specified.
No.
Block Write Data
For data details, see:
0
No selection
1
Command 1 (FA00)
“8.1 Command by communication”
2
Command 2 (FA20)
“8.1 Command by communication”
3
Frequency Command Value (FA01)
“8.1 Command by communication”
4
Terminal Board Output Data (FA50)
“8.3 Control of input/put signals from com-
munication”
5
Communication Analog Output (FA51)
“8.3 Control of input/put signals from com-
munication”
No.
Block Read Data
For data details, see:
0
No selection
1
Status 1 (FD01)
“8.2 Monitoring from communication”
2
Output Frequency (FD00)
“8.2 Monitoring from communication”
3
Output Current (FE03)
“9. Parameter data”
4
Output Voltage (FE05)
“9. Parameter data”
5
Alarm Information (FC91)
“8.2 Monitoring from communication”
6
PID Feedback Value (FE22)
“9. Parameter data”
7
Input Terminal Board Monitoring (FD06)
“8.3 Control of input/put signals from
communication”
8
Output Terminal Board Monitoring (FD07)
“8.3 Control of input/put signals from
communication”
9
Analog Monitoring VIA (FE35)
“8.3 Control of input/put signals from
communication”
10
Analog Monitoring VIB (FE36)
“8.3 Control of input/put signals from
communication”
