E6581222
47
8.2. Monitoring from the computer
This section explains how to monitor the operating status of the inverter from the computer.
„
Monitoring of the operation frequency from the computer (FE00, FD00)
Operation frequency (frequency immediately before the occurrence of a trip):
Communication Number FE00 (Minimum unit: 0.01 Hz)
Operation frequency (current frequency): Communication Number FD00 (Minimum unit: 0.01 Hz)
Ex.: Monitoring of operation frequency (during 50 Hz operation) ... (1388H = 5000d, 5000 x 0.1 = 50
Hz)
Computer → Inverter Inverter → Computer
(RFD00)
CR
(RFD001388)
CR
„ Inverter operating status (FE01, FD01)
Operating status (status immediately before the occurrence of a trip):
Communication Number FE01
Operating status (current status): Communication Number FD01
Table 2 Data construction of inverter operating status (FE00/FD00) (*: FD01 supports the VF-S11 and later models.)
Bit Specifications 0 1 S7 S9 S11/nC1 Remarks
0 Failure FL No output Output in prog-
ress
- - 9
1 Failure Not tripped Tripped
- - 9
Trip statuses include 
and trip retention status.
2 Alarm No alarm Alarm issued
- - 9
3 Reserved - -
- - -
4 Motor section (1 or 2)
(THR 2 selection)
Motor 1 (THR 1) Motor 2 (THR 2)
- 9 9
THR1: PT=set value, vL, vb, Thr
THR2:PT=0, F170, F172, F173
5 PI control OFF PI control
permitted
PI control
prohibited
- 9 9
6 Acceleration/deceleration
pattern selection (1 or 2)
Acceleration/
deceleration
pattern 1 (AD 1)
Acceleration/
deceleration
pattern 2 (AD 2)
9 9 9
AD1 :ACC, DEC,
AD2 :F500, F501
7 DC braking OFF Forced DC
braking
9 9 9
8 Jog run OFF Jog run
9 9 9
9 Forward/reverse run Forward run Reverse run
9 9 9
10 Run/stop Stop Run
9 9 9
11 Coast stop (ST=OFF) ST=ON ST=OFF
- 9 9
12 Emergency stop Not emergency
stop status
Emergency stop
status
- 9 9
13 Standby ST=ON Start-up process Standby
- - 9
Standby: Initialization completed,
not failure stop status, not alarm
stop status (MOFF, LL forced
stop or forced stop due to a
momentary power failure),
ST=ON, and RUN=ON
14 Standby Start-up process Standby
- - 9
Standby: Initialization completed,
not failure stop status, and not
alarm stop status (MOFF, LL
forced stop or forced stop due to
a momentary power failure)
15 Reserved - -
- - -
