33
APPENDIX
Specifications
The TDP-B1 must be operated and stored within the temperature and
humidity ranges specified.
Temperature
Operating 50 to 104
°
F (10 to 40
°
C)
Non-operating -4 to 158
°
F (-20 to 70
°
C)
Humidity
Operating and non-oper. 5% to 95% relative humidity, non-condensing
Dimensions
8.9 x 10 x 2.8 inches (22.6 x 25.4 x 7.1 cm)
Weight
4.8 lbs. (2.2 kg) unpacked
Altitude
Operating 0 to 10,000 feet (3,048 meters)
Non-operating 0 to 40,000 feet (12,192 meters)
Optics
Focus Range 4.9 - 16 feet (1.5-5 m)
Lamp
Type 120-watt VIP lamp
Input Power Requirements
100-120VAC 6A;50/60Hz
200-240VAC 3A; 50Hz
Audio Input
Input Impedance 10K ohm nominal, AC coupled
Maximum Input Voltage (L
IN
+ R
IN
)
PEAK
< 4.5 V for THD
≤
0.3%
L
IN
or R
IN
< 2.0 Vrms for THD
≤
0.3%
Sensitivity 100 mV at 1 KHz for 88 dB SPL at 1 meter
Connector Type 3.5 mm (1/8 inch) stereo phone mini
