15
Adjusting the Projector
To focus the image, rotate the focus ring (Figure 9) until the image is
clear. To zoom the image, rotate the zoom ring. This adjusts the image
size without affecting focus.
F IGURE 9
Focus ring and zoom ring
The projector is equipped with a self-locking, quick-release elevator
foot and button (Figure 10).
To raise the projector:
1 Press and hold the elevator button (Figure 10).
2 Raise the projector to the height you want, then release the button to
lock the elevator foot into position.
F IGURE 10
Adjusting the height of the projector
focus ring
zoom ring
elevator button
elevator foot
(under finger)
