7 Front and Rear Panels
7-2 Phaser 220i and Phaser 220e Color Printers
Rear panel DIP switches (Phaser 220e)
In this table, D indicates that the switch is down; U indicates that the switch
is up.
Phaser 220e rear panel DIP switches
Switch Function Settings
1 Reset/run Up: The printer resets and does not accept data
while the switch is in this position.
Down. The printer runs a self-test, then proceeds
to run normally. Leave the switch
down for normal
operation.
2, 3, and 4 Serial port
Color correction
Configuration page See the next table, “Phaser 220e DIP Switches 2,
3, and 4.”
Phaser 220e DIP Switches 2, 3, and 4
Switches Operation Features
2 3 4 Serial port Color correction
D D D Normal Variable None
U D D Fixed serial parameters Fixed None
D U D Color correction Variable Vivid blue
U U D For service personnel only Variable None
D D U Print configuration page* Variable None
U D U Enable sample prints Variable None
D U U For service personnel only Variable None
U U U For service personnel only Variable None
*To print the configuration page, first set Switches 2, 3, and 4 down. After about
5 seconds, set Switch 4 up.
