2 Getting Set Up
2-24 Phaser 220i and Phaser 220e Color Printers
8. Select your printer and click on OK .
9. The driver software you need is automatically installed.
10. Assign the printer to a port:
a. Select the printer from the list of installed printers.
b. Choose the Connect button to display the Connect dialog box.
c. Set the Transmission Retry value to 995. Refer to your
Windows documentation for details.
d. Select a port:
Interface Select
Parallel LPT1 or LPT2
Serial COM1 or COM2
Network Network button
If you selected a parallel port, go on to step e.
If you selected a serial port, click on the Settings button to
open the Settings dialog box. Fill in each item according to
your configuration, then click on
OK . Refer to your Windows
documentation for details or ask your network administrator
for help.
If you clicked on the Network button, the Printers – Network
Connections
dialog box appears. Fill in each item according
to your configuration. Refer to your Windows documentation
for details or ask your network administrator for help.
Note The printer’s configuration page contains the information you
need to set up the printer port. For information on generating a
configuration page, see “Generating the configuration page” on
page 6-13.
e. Click on OK in the Connect dialog box and close the Printers
dialog box.
