Tektronix 220e User Manual
Page 103
User Manual
A-1
Appendix
A
Technical Notes
Printer ports
Parallel port
The printer has a standard unidirectional, byte-wide parallel, synchronous
port. When you use the parallel port, be sure to type this command at the
PC (if LPT1 is not available, use LPT2):
MODE LPT1:,,P
The table on the next page shows the parallel port's connected pins.
Other pins are not connected. Signal names ending with a dash (-) are
asserted low.
