UH-PRC001-EN 46
Electric
Power
Accessory
Model Motor Operating MAX
Number Type Voltage AMP MCA FUSE HP RPM
Explosion Proof
102 with Thermal Overload 208-230/460/60/3 1.0-1.0/0.5 1.3-1.3/0.6 15-15/15 1/6 1140
Explosion Proof
122,146,166 with Thermal Overload 208-230/460/60/3 1.0-1.0/0.5 1.3-1.3/0.6 15-15/15 1/6 1140
Explosion Proof
202 with Thermal Overload 208-230/460/60/3 1.1-1.1/0.55 1.4-1.4/0.7 15-15/15 1/4 1140
Explosion Proof
252 with Thermal Overload 208-230/460/60/3 1.1-1.1/0.55 1.4-1.4/0.7 15-15/15 1/4 1140
Explosion Proof
280 with Thermal Overload 208-230/460/60/3 1.9-1.9/0.95 2.4-2.4/1.2 15-15/15 1/2 1140
Explosion Proof
336,384 with Thermal Overload 208-230/460/60/3 3.1-3.2/1.6 3.9-4.0/2.0 15-15/15 3/4 1145
Explosion Proof
500,600 with Thermal Overload 230/460/60/3 5.2/2.6 6.5/3.3 15/15 1-½ 1150
Explosion Proof
720 with Thermal Overload 208-230/460/60/3 10.0-10.0/5.0 12.5-12.5/6.3 20-20/15 3 1150
Accessory
Model Motor Operating MAX
Number Type Voltage AMP MCA FUSE HP RPM
42-252 Totally Enclosed 575/60/3 0.6 0.8 15 1/3 1140
280 Totally Enclosed 575/60/3 0.8 1.0 15 1/2 1140
336,384 Totally Enclosed 575/60/3 1.3 1.6 15 3/4 1140
500,600 Totally Enclosed 575/60/3 2.0 2.5 15 1-½ 1160
720 Totally Enclosed 575/60/3 3.75 4.7 15 3 1165
CAUTION: Select appropriate AMP, MCA, and MAX FUSE for the multiple voltage motors. For example, the AMP, MCA, and MAX FUSE for Model 720 with a 230 volt Explosion Proof motor
is 10.0, 12.5, and 20 respectively.
Table EP – 6 Electric Power — Model P Unit Heater — Motor
Table EP - 7 Electric Power — Model P Unit Heater — Motor
