UH-PRC001-EN 30
Performance
Data
Table PD-2 (Continued) – Model S Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. Hot Water with Turbulators and 132 Fin Series
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 260 F 300 F 340 F 380 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
20 18.0 1.85 112.6 .07 .08 22.9 2.36 127.1 .10 .11 27.9 2.88 141.7 .13 .15 — — — — —
20-W2 30 14.5 .99 102.4 .02 .03 19.5 1.34 116.9 .04 .04 24.4 1.68 131.5 .05 .06 29.4 2.02 146.1 .07 .08
CFM 315 40 11.0 .57 92.2 .01 .01 16.0 .82 106.8 .02 .02 21.0 1.08 121.3 .02 .03 26.0 1.34 135.9 .03 .04
RPM 1075 50 — — — — — 12.5 .52 96.6 .01 .01 17.5 .72 111.2 .01 .01 22.5 .93 125.7 .02 .02
HP 1/50 60 — — — — — — — — — — 14.0 .48 101.0 .01 .01 19.0 .65 115.6 .01 .01
40 34.1 1.76 121.1 .10 .12 44.2 2.28 139.3 .15 .18 — — — — — — — — — —
50 29.9 1.23 113.6 .06 .07 40.1 1.65 131.8 .09 .10 — — — — — — — — — —
38-W2 60 25.7 .88 106.1 .03 .04 35.9 1.23 124.3 .05 .06 46.0 1.58 142.5 .08 .09 — — — — —
CFM 514 80 17.3 .45 91.1 .01 .01 27.5 .71 109.3 .02 .03 37.7 .97 127.5 .03 .04 47.8 1.23 145.8 .05 06
RPM 1550 100 — — — — — 19.1 .39 94.3 .01 .01 29.3 .60 112.5 .02 .02 39.5 .81 130.8 .02 .03
HP 1/20 120 — — — — — — — — — — 20.9 .36 97.5 .01 .01 31.1 .53 115.7 .01 .01
140 — — — — — — — — — — — — — — — 22.7 .33 100.7 .01 .01
40 34.6 1.78 120.2 .10 .12 45.0 2.32 138.2 .15 .18 — — — — — — — — — —
50 30.4 1.25 112.9 .06 .07 40.7 1.68 130.8 .09 .11 — — — — — — — — — —
42-W2 60 26.2 .90 105.5 .03 .04 36.5 1.25 123.4 .06 .07 46.8 1.61 141.4 .08 .09 — — — — —
CFM 530 80 17.7 .46 90.7 .01 .01 28.0 .72 108.7 .02 .03 38.3 .99 126.6 .04 .04 48.6 1.25 144.6 .05 .06
RPM 1550 100 — — — — — 19.5 .40 93.9 .01 .01 29.8 .61 111.9 .02 .02 40.2 .83 129.8 .03 .03
HP 1/20 120 — — — — — — — — — — 21.4 .37 97.1 .01 .01 31.7 .54 115.1 .01 .02
140 — — — — — — — — — — — — — — — 23.2 .34 100.3 .01 .01
40 56.1 2.89 128.4 .32 .38 71.1 3.67 146.8 .45 .54 — — — — — — — — — —
50 51.2 2.11 122.5 .19 .23 66.3 2.73 140.9 .28 .33 — — — — — — — — — —
60-W2 60 46.4 1.59 116.6 .12 .14 61.5 2.11 135.0 .18 .22 — — — — — — — — — —
CFM 755 80 36.7 .95 104.8 .05 .06 51.8 1.33 123.2 .09 .10 66.9 1.72 141.6 .12 .15 — — — — —
RPM 1550 100 27.1 .56 93.0 .02 .03 42.1 .87 111.4 .04 .05 57.2 1.18 129.8 .07 .08 72.3 1.49 148.2 .09 .11
HP 1/20 120 17.4 .30 81.2 .01 .01 32.5 .56 99.6 .02 .03 47.5 .82 118.0 .04 .04 62.6 1.08 136.4 .05 .07
140 — — — — — 22.8 .34 87.8 .01 .01 37.9 .56 106.2 .02 .02 52.9 .78 124.6 .03 .04
160 — — — — — — — — — — 28.2 .36 94.4 .01 .01 43.3 .56 112.8 .02 .02
40 64.4 3.32 119.2 .40 .48 81.7 4.21 135.0 .57 .67 — — — — — — — — — —
50 59.0 2.43 114.2 .24 .29 76.3 3.14 130.0 .35 .42 93.5 3.85 145.8 .46 .55 — — — — —
70-W2 60 53.6 1.84 109.2 .15 .18 70.8 2.43 125.0 .23 .27 88.1 3.02 140.8 .31 .37 — — — — —
CFM 1004 80 42.7 1.10 99.2 .07 .08 59.9 1.54 115.0 .11 .13 77.2 1.99 130.8 .16 .19 94.4 2.43 146.7 .20 .24
RPM 1550 100 31.8 .65 89.2 .03 .03 49.0 1.01 105.0 .06 07 66.3 1.37 120.8 .09 .10 83.5 1.72 136.7 .12 .14
HP 1/8 120 20.9 .36 79.2 .01 .01 38.1 .65 95.0 .03 .03 55.4 .95 110.8 .05 .06 72.6 1.25 126.7 .07 .08
140 — — — — — 27.2 .40 85.0 .01 .01 44.5 .65 100.8 .03 .03 61.7 .91 116.7 .04 .05
160 — — — — — — — — — — 33.6 .43 90.8 .01 .02 50.8 .65 106.7 .02 .03
50 82.0 3.38 125.0 .55 .66 104.3 4.30 142.7 .77 .92 — — — — — — — — — —
60 76.1 2.62 120.4 .37 .44 98.4 3.38 138.0 .52 .63 — — — — — — — — — —
80 64.4 1.66 111.1 .17 .21 86.7 2.23 128.7 .27 .32 108.9 2.81 146.4 .37 .44 — — — — —
90-W2 100 52.7 1.09 101.8 .09 .11 74.9 1.54 119.4 .15 .18 97.2 2.00 137.1 .21 .25 — — — — —
CFM 1162 120 40.9 .70 92.5 .04 .05 63.2 1.09 110.1 .08 .10 85.5 1.47 127.8 .13 .15 107.7 1.85 145.4 .18 .21
RPM 1550 140 29.2 .43 83.2 .02 .02 51.5 .76 100.8 .05 .06 73.7 1.09 118.5 .08 .10 96.0 1.41 136.1 .12 .14
HP 1/8 160 17.5 .23 73.9 .01 .01 39.7 .51 91.5 .03 .03 62.0 .80 109.2 .05 .06 84.3 1.09 126.8 .08 .09
180 — — — — — 28.0 .32 82.2 .01 .01 50.3 .58 99.9 .03 .03 72.5 .83 117.5 .05 .06
40 96.9 4.99 122.6 1.05 1.25 121.5 6.26 138.5 1.43 1.71 — — — — — — — — — —
50 90.3 3.72 118.3 .65 .78 114.9 4.74 134.2 .91 1.09 — — — — — — — — — —
60 83.8 2.88 114.1 .43 .51 108.4 3.72 130.0 .62 .73 133.0 4.57 145.9 .81 .96 — — — — —
100-W2 80 70.7 1.82 105.6 .20 .24 95.3 2.45 121.5 .31 .37 119.9 3.09 137.4 .43 .51 — — — — —
CFM 1427 100 57.6 1.19 97.2 .10 .12 82.2 1.69 113.1 .17 .21 106.8 2.20 129.0 .25 .30 131.4 2.71 144.9 .33 .39
RPM 1550 120 44.5 .76 88.7 .05 .06 69.1 1.19 104.6 .10 .12 93.7 1.61 120.5 .15 .18 118.3 2.03 136.4 .21 .25
HP 1/8 140 31.4 .46 80.3 .02 .03 56.0 .82 96.2 .05 .06 80.6 1.19 112.1 .09 .11 105.2 1.55 128.0 .13 .16
160 18.3 .24 71.8 .01 .01 42.9 .55 87.7 .03 .03 67.5 .87 103.6 .06 .07 92.1 1.19 119.5 .09 .11
180 — — — — — 29.8 .34 79.3 .01 .02 54.4 .62 95.2 .03 .04 79.0 .91 111.1 .06 .07
60 115.3 3.96 124.0 .97 1.16 147.3 5.06 141.7 1.36 1.62 — — — — — — — — — —
80 100.4 2.59 115.7 .49 .58 132.4 3.41 133.5 .72 .86 164.4 4.24 151.2 .97 1.15 — — — — —
126-W2 100 85.5 1.76 107.4 .26 .31 117.5 2.42 125.2 .42 .50 149.5 3.08 143.0 .58 .69 — — — — —
CFM 1661 120 70.6 1.21 99.2 .14 .17 102.6 1.76 116.9 .25 .30 134.6 2.31 134.7 .37 .44 — — — — —
RPM 1100 140 55.7 .82 90.9 .08 .09 87.7 1.29 108.7 .15 .18 119.7 1.76 126.4 .24 .29 151.7 2.23 144.2 .33 .39
HP 1/6 160 40.8 .53 82.6 .04 .05 72.8 .94 100.4 .09 .11 104.8 1.35 118.2 .16 .19 136.8 1.76 135.9 .23 .27
180 25.9 .30 74.4 .02 .02 57.9 .66 92.1 .05 .06 89.9 1.03 109.9 .10 .12 121.9 1.40 127.6 .16 .19
