29 UH-PRC001-EN
Performance
Data
Table PD-2 (Continued) – Model S Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. Hot Water with Turbulators and 132 Fin Series
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 180 F 200 F 220 F 240 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
20 117.6 12.12 100.3 8.49 10.12 140.5 14.48 108.1 10.71 12.77 163.4 16.84 116.0 13.33 15.90 — — — — —
25 112.7 9.29 98.6 5.52 6.59 135.6 11.18 106.5 7.01 8.36 158.5 13.06 114.3 8.81 10.50 181.3 14.95 122.1 10.67 12.73
186-W2 30 107.8 7.41 96.9 3.83 4.57 130.7 8.98 104.8 4.92 5.87 153.5 10.55 112.6 6.21 7.41 176.4 12.12 120.4 7.58 9.04
CFM 2690 40 98.0 5.05 93.6 2.08 2.47 120.9 6.23 101.4 2.74 3.27 143.7 7.41 109.2 3.50 4.17 166.6 8.58 117.1 4.33 5.16
RPM 1100 50 88.2 3.63 90.2 1.23 1.47 111.0 4.58 98.0 1.68 2.01 133.9 5.52 105.9 2.17 2.59 156.8 6.46 113.7 2.73 3.26
HP 1/4 60 78.3 2.69 86.8 .76 .91 101.2 3.48 94.7 1.09 1.30 124.1 4.26 102.5 1.43 1.70 147.0 5.05 110.4 1.83 2.19
70 68.5 2.02 83.5 .48 .58 91.4 2.69 91.3 .73 .87 114.3 3.36 99.1 .98 1.17 137.1 4.04 107.0 1.28 1.53
80 — — — — — 81.6 2.10 87.9 .49 .59 104.4 2.69 95.8 .69 .82 127.3 3.28 103.6 .92 1.09
15 163.8 22.50 107.2 5.82 6.94 194.7 26.75 116.1 7.32 8.73 225.6 30.99 125.0 9.07 10.81 256.4 35.24 133.9 10.88 12.97
20 156.6 16.14 105.1 3.39 4.04 187.5 19.32 114.0 4.29 5.12 218.4 22.50 122.9 5.36 6.40 249.2 25.69 131.8 6.47 7.72
230-W2 25 149.4 12.32 103.0 2.19 2.61 180.3 14.86 111.9 2.80 3.33 211.2 17.41 120.8 3.52 4.20 242.1 19.96 129.7 4.28 5.11
CFM 3200 30 142.2 9.77 101.0 1.51 1.80 173.1 11.89 109.9 1.95 2.33 204.0 14.01 118.7 2.47 2.95 234.9 16.14 127.6 3.03 3.61
RPM 1100 40 127.8 6.59 96.8 .80 .96 158.7 8.18 105.7 1.07 1.28 189.6 9.77 114.6 1.38 1.64 220.5 11.36 123.5 1.71 2.04
HP 1/4 50 113.4 4.68 92.7 .46 .55 144.3 5.95 101.6 .65 .77 175.2 7.22 110.5 .84 1.00 206.1 8.50 119.4 1.07 1.27
60 99.0 3.40 88.5 .28 .33 129.9 4.46 97.4 .41 .49 160.8 5.52 106.3 .55 .65 191.7 6.59 115.2 .71 .84
70 84.7 2.49 84.4 .17 .20 115.6 3.40 93.3 .27 .32 146.4 4.31 102.2 .37 .44 177.3 5.22 111.1 .49 .58
80 — — — — — — — — — — — — — — — 162.9 4.20 106.9 .34 .41
20 173.1 17.84 100.6 4.00 4.77 207.4 21.37 108.6 5.07 6.05 241.6 24.90 116.6 6.34 7.56 275.8 28.42 124.6 7.65 9.13
25 165.1 13.61 98.7 2.58 3.08 199.3 16.43 106.7 3.30 3.93 2335 19.25 114.7 4.16 4.96 267.8 22.07 122.7 5.06 6.05
260-W2 30 157.0 10.79 96.8 1.78 2.12 191.2 13.14 104.8 2.30 2.74 225.5 15.49 112.8 2.92 3.48 259.7 17.84 120.9 3.57 4.26
CFM 3933 40 140.9 7.26 93.0 .94 1.12 175.1 9.02 101.0 1.26 1.50 209.4 10.79 109.1 1.62 1.93 243.6 12.55 117.1 2.02 2.40
RPM 1100 50 124.8 5.14 89.2 .54 .65 159.0 6.56 97.3 .76 .90 193.3 7.97 105.3 .99 1.18 227.5 9.38 113.3 1.26 1.50
HP 1/2 60 108.7 3.73 85.5 .33 .39 142.9 4.91 93.5 .48 .57 177.1 6.08 101.5 .64 .76 211.4 7.26 109.5 .83 .99
70 92.6 2.73 81.7 .20 .24 126.8 3.73 89.7 .31 .37 161.0 4.74 97.7 .43 .51 195.3 5.75 105.8 .57 .68
80 — — — — — 110.7 2.85 85.9 .20 .24 144.9 3.73 94.0 .30 .35 179.1 4.62 102.0 .40 .48
20 223.0 22.98 107.2 7.98 9.51 266.2 27.43 116.4 10.02 11.95 309.4 31.89 125.6 12.45 14.95 352.7 36.34 134.7 14.96 17.84
25 213.9 17.63 105.3 5.21 6.21 257.1 21.20 114.5 6.59 7.86 300.3 24.76 123.6 8.25 9.84 343.6 28.32 132.8 9.97 11.89
320-W2 30 204.8 14.07 103.4 3.63 4.33 248.0 17.04 112.5 4.64 5.53 291.2 20.01 121.7 5.84 6.96 334.5 22.98 130.9 7.10 8.47
CFM 4350 40 186.6 9.61 99.5 1.98 2.36 229.8 11.84 108.7 2.60 3.10 273.0 14.07 117.8 3.30 3.94 316.3 16.30 127.0 4.07 4.86
RPM 1100 50 168.4 6.94 95.7 1.18 1.41 211.6 8.72 104.8 1.60 1.91 254.8 10.50 114.0 2.06 2.46 298.1 12.29 123.2 2.58 3.08
HP 1/2 60 150.2 5.16 91.8 .74 .88 193.4 6.64 101.0 1.05 1.25 236.6 8.13 110.1 1.36 1.63 279.9 9.61 119.3 1.74 2.08
70 132.0 3.89 88.0 .47 .56 175.2 5.16 97.1 .70 .84 218.5 6.43 106.3 .94 1.12 261.7 7.70 115.4 1.22 1.46
80 — — — — — 157.0 4.05 93.3 .48 .57 200.3 5.16 102.4 .67 .80 243.5 6.27 111.6 .88 1.05
20 249.7 25.73 101.6 9.61 11.46 298.1 30.72 109.7 12.07 14.40 346.5 35.71 117.8 15.00 17.89 — — — — —
25 239.5 19.75 99.9 6.28 7.48 287.9 23.74 108.0 7.93 9.46 336.4 27.73 116.1 9.94 11.85 384.8 31.72 124.2 12.01 14.33
354-W2 30 229.3 15.76 98.2 4.37 5.21 277.8 19.08 106.3 5.59 6.66 326.2 22.41 114.4 7.03 8.38 374.6 25.73 122.5 8.55 10.20
CFM 5528 40 209.0 10.77 94.8 2.38 2.84 257.4 13.26 102.9 3.13 3.73 305.8 15.76 111.0 3.97 4.74 354.2 18.25 119.1 4.90 5.85
RPM 1100 50 188.6 7.77 91.4 1.42 1.69 237.0 9.77 99.5 1.93 2.30 285.4 11.76 107.6 2.48 2.96 333.8 13.76 115.7 3.11 3.71
HP 1/2 60 168.2 5.78 88.0 .89 1.06 216.6 7.44 96.1 1.26 1.50 265.0 9.10 104.2 1.64 1.96 313.4 10.77 112.3 2.10 2.50
70 147.8 4.35 84.6 .57 .68 196.2 5.78 92.7 .85 1.01 244.6 7.20 100.8 1.13 1.35 293.1 8.63 108.9 1.47 1.75
80 — — — — — 175.8 4.53 89.3 .58 .69 224.3 5.78 97.4 .80 .96 272.7 7.02 105.5 1.06 1.26
20 282.5 29.12 102.3 10.88 12.90 340.0 35.05 110.8 14.25 17.23 396.0 40.92 119.2 17.59 21.10 454.0 46.80 127.9 21.25 26.20
25 270.0 22.27 100.4 7.10 8.47 324.0 26.72 108.5 9.53 11.25 382.0 31.51 117.1 12.25 14.62 440.0 36.29 125.8 14.95 18.10
400-W2 30 260.0 17.87 98.9 4.91 5.84 313.0 21.51 106.8 6.66 7.97 369.0 25.36 115.2 8.82 10.36 428.0 29.42 124.0 11.05 13.10
CFM 6017 40 235.0 12.11 95.1 2.61 3.06 289.0 14.90 103.2 3.65 4.24 346.0 17.84 111.7 4.88 5.81 405.0 20.88 120.6 6.32 7.61
RPM 1140 50 213.0 8.78 91.9 1.56 1.94 266.0 10.97 99.8 2.21 2.62 323.0 13.32 108.3 3.03 3.51 381.0 15.71 117.0 3.97 4.60
HP 3/4 60 190.0 6.53 88.4 1.04 1.31 243.0 8.35 96.3 1.43 1.82 298.0 10.24 104.6 1.96 2.39 357.0 12.27 113.4 2.65 3.14
70 168.0 4.95 85.1 .75 .96 221.0 6.51 93.1 1.04 1.28 276.0 8.13 101.3 1.37 1.72 335.0 9.87 110.1 1.87 2.30
90 — — — — — 197.0 5.08 89.5 .77 .98 252.0 6.49 97.7 1.05 1.30 312.0 8.04 106.7 1.35 1.71
