Trane UH-PRC001-EN - Manual (Page 40)

UH-PRC001-EN 40
Performance
Data
Table PD-5 (Continued) – Model P-L Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. (Capacities shown are for units with all Air Ports open)
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 260 F 300 F 340 F 380 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
42-P-L
CFM 668 50 — — — — — 24.7 1.02 94.0 .01 .02 32.9 1.36 105.4 .02 .03 41.1 1.69 116.7 .03 .04
RPM 1550 60 — — — — — — — — — — 27.9 .96 98.6 .01 .01 36.2 1.24 109.9 .02 .02
HP 1/40
42-P-L
CFM 470 50 — — — — — 18.0 .74 95.2 .01 .01 23.7 .98 106.4 .01 .01 29.4 1.21 117.6 .02 .02
RPM 1150 60 — — — — — — — — — — — — — — — 26.1 .90 111.2 .01 .01
HP 1/40
64-P-L 50 33.3 1.37 85.6 .02 .03 47.3 1.95 96.3 .05 .06 61.2 2.52 107.0 .07 .10 75.2 3.10 117.7 .11 .14
CFM 1200 60 26.1 .90 80.0 .01 .01 40.0 1.37 90.7 .02 .03 53.9 1.85 101.4 .04 .05 67.9 2.33 112.1 .06 .08
RPM 1550 80 — — — — — — — — — — 39.4 1.01 90.3 .01 .02 53.3 1.37 101.0 .02 .03
HP 1/20 100 — — — — — — — — — — — — — — — 38.8 .80 89.8 .01 .01
64-P-L 50 26.5 1.09 88.3 .02 .02 37.3 1.54 99.9 .03 .04 48.2 1.99 111.5 .05 .06 59.0 2.43 123.1 .07 .09
CFM 862 60 — — — — — 31.8 1.09 94.0 .02 .02 42.6 1.46 105.6 .03 .03 53.5 1.84 117.2 .04 .05
RPM 1150 80 — — — — — — — — — — 31.5 .81 93.7 .01 .01 42.4 1.09 105.3 .01 .02
HP 1/20
80-P-L 50 39.7 1.64 86.9 .02 .03 56.1 2.31 98.0 .04 .05 72.5 2.99 109.1 .06 .08 88.9 3.66 120.3 .09 .12
CFM 1360 60 31.2 1.07 81.2 .01 .01 47.6 1.64 92.3 .02 .03 64.0 2.20 103.4 .04 .05 80.4 2.76 114.5 .05 .07
RPM 1550 80 — — — — — — — — — — 47.1 1.21 91.9 .01 .01 63.5 1.64 103.0 02 .03
HP 1/20 100 — — — — — — — — — — — — — — — 46.6 .96 91.6 .01 .01
80-P-L 50 31.6 1.30 89.3 .01 .02 44.5 1.83 101.2 .03 .03 57.4 2.36 113.1 .04 .05 70.2 2.89 125.1 .06 .08
CFM 995 60 — — — — — 37.9 1.30 95.1 .01 .02 50.8 1.75 107.1 .02 .03 63.7 2.19 119.0 .03 .04
RPM 1150 80 — — — — — — — — — — 37.7 .97 94.9 .01 .01 50.6 1.30 106.8 .01 .02
HP 1/20
102-P-L 50 65.2 2.69 94.3 .07 .09 85.4 3.52 104.9 .11 .15 105.7 4.36 115.6 .17 .22 126.0 5.19 126.3 .23 .30
CFM 1752 60 57.9 1.99 90.5 .04 .05 78.2 2.69 101.1 .07 .09 98.5 3.38 111.8 .10 .13 118.7 4.08 122.5 .14 .19
RPM 1070 80 43.4 1.12 82.9 .01 .02 63.7 1.64 93.5 .03 .04 84.0 2.16 104.2 .04 .06 104.3 2.69 114.8 .07 .09
HP 1/8 100 — — — — — 49.2 1.01 85.9 .01 .01 69.5 1.43 96.6 .02 .03 89.8 1.85 107.2 .03 04
120 — — — — — — — — — — 55.0 .95 88.9 .01 .01 75.3 1.29 99.6 .02 .02
50 56.3 2.32 94.6 .05 .07 73.6 3.03 105.2 .09 .11 90.9 3.75 115.9 .12 .16 108.2 4.46 126.5 .17 .22
102-P-L 60 50.2 1.72 90.9 .03 .04 67.5 2.32 101.5 .05 .07 84.8 2.91 112.2 .08 .10 102.1 3.51 122.8 .11 .14
CFM 1499 80 — — — — — 55.4 1.43 94.1 .02 .03 72.7 1.87 104.7 .03 .04 90.0 2.32 115.3 .05 .07
RPM 850 100 — — — — — — — — — — 60.6 1.25 97.3 .02 .02 77.9 1.61 107.9 .03 .03
HP 1/8 120 — — — — — — — — — — — — — — — 65.8 1.13 100.5 .01 .02
50 84.8 3.49 95.8 .11 .15 111.5 4.59 107.1 .19 .24 138.2 5.69 118.4 .28 .36 164.8 6.79 129.7 .38 .49
122-P-L 60 75.1 2.58 91.1 .06 .08 101.7 3.49 103.0 .11 .15 128.4 4.41 114.3 .17 .22 155.1 5.33 125.6 .24 .31
CFM 2180 80 55.6 1.43 83.5 .02 .03 82.3 2.12 94.8 .04 .06 109.0 2.81 106.1 .07 .10 135.7 3.49 117.4 .11 .14
RPM 1100 100 — — — — — 62.8 1.29 86.6 .02 .02 89.5 1.84 97.8 .03 .04 116.2 2.39 109.1 .05 .07
HP 1/6 120 — — — — — — — — — — 70.0 1.20 89.6 .01 .02 96.7 1.66 100.9 .03 .04
140 — — — — — — — — — — — — — — — 77.3 1.14 92.7 .01 .02
50 101.0 4.16 99.4 .15 .21 131.1 5.40 111.2 .24 .33 161.2 6.64 122.9 .35 .47 191.2 7.88 134.7 .48 .64
60 91.1 3.13 95.6 .09 .12 121.2 4.16 107.3 .15 .20 151.3 5.20 119.1 .22 .30 181.4 6.23 130.8 .31 .41
146-P-L 80 71.4 1.84 87.9 .03 .05 101.5 2.61 99.6 .06 .09 131.5 3.39 111.4 .01 .14 161.6 4.16 123.1 .15 .19
CFM 2360 100 — — — — — 81.7 1.68 91.9 .03 .04 111.8 2.30 103.7 .05 .07 141.9 2.92 115.4 .08 .10
RPM 1100 120 — — — — — — — — — — 92.0 1.58 95.9 .02 .03 122.1 2.10 107.7 .04 .05
HP 1/6 140 — — — — — — — — — — 72.3 1.06 88.2 .01 .02 102.4 1.51 100.0 .02 .03
160 — — — — — — — — — — — — — — — 82.6 1.06 92.3 .01 .02
50 119.1 4.91 97.6 .14 .19 154.5 6.37 108.8 .23 .30 189.9 7.83 119.9 .33 .43 225.3 9.29 131.1 .44 .59
60 107.6 3.69 93.9 .08 .11 142.9 4.91 105.1 .14 .19 178.3 6.13 116.3 .21 .27 213.7 7.34 127.5 .28 .38
166-P-L 80 84.4 2.17 86.6 .03 .04 119.8 3.09 97.8 .06 .08 155.2 4.00 109.0 .09 .12 190.6 4.91 120.2 .13 .18
CFM 2920 100 — — — — — 96.7 1.99 90.5 .03 .03 132.1 2.72 101.7 .05 .06 167.5 3.45 112.9 .07 .09
RPM 1100 120 — — — — — — — — — — 108.9 1.87 94.4 .02 .03 144.3 2.48 105.6 .04 .05
HP 1/6 140 — — — — — — — — — — 85.8 1.26 87.1 .01 .01 121.2 1.78 98.2 .02 .03
160 — — — — — — — — — — — — — — — 98.0 1.26 90.9 .01 .01
