41 UH-PRC001-EN
Performance
Data
Table PD-5 (Continued) – Model P-L Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. (Capacities shown are for units with all Air Ports open)
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 180 F 200 F 220 F 240 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
10 114.3 23.56 91.1 2.83 3.76 135.8 27.98 96.9 3.85 5.11 157.2 32.39 102.7 5.01 6.64 — — — — —
15 107.2 14.73 89.1 1.17 1.56 128.6 17.67 95.0 1.63 2.16 150.1 20.62 100.8 2.14 2.84 171.5 23.56 106.6 2.72 3.60
202-P-L 20 100.1 10.32 87.2 .60 .80 121.5 12.52 93.0 .85 1.13 142.9 14.73 98.9 1.14 1.51 164.4 16.94 104.7 1.46 1.94
CFM 3390 25 93.0 7.67 85.3 .35 .46 114.4 9.43 91.1 .50 .67 135.8 11.20 96.9 .68 .91 157.3 12.96 102.8 .88 1.18
RPM 1100 30 85.9 5.90 83.3 .21 .28 107.3 7.37 89.2 .32 .42 128.7 8.84 95.0 .44 .58 150.1 10.32 100.8 .58 .77
HP 1/4 40 71.6 3.69 79.5 .09 .12 93.1 4.80 85.3 .14 .19 114.5 5.90 91.1 .21 .27 135.9 7.00 97.0 .28 .37
50 57.4 2.37 75.6 .04 .05 78.8 3.25 81.4 .07 .09 100.3 4.13 87.3 .11 .14 121.7 5.02 93.1 .15 .20
60 — — — — — 64.6 2.22 77.6 .03 .05 86.0 2.96 83.4 .06 .06 107.5 3.69 89.2 .09 .11
10 142.3 29.33 89.1 5.01 6.66 168.5 34.72 94.5 6.75 8.98 — — — — — — — — — —
15 135.0 18.54 87.6 2.13 2.84 161.1 22.14 93.0 2.91 3.88 187.3 25.73 98.3 3.80 5.05 213.5 29.33 103.7 4.78 6.36
252-P-L 20 127.6 13.15 86.1 1.12 1.50 153.8 15.85 91.4 1.56 2.08 180.0 18.54 96.8 2.06 2.74 206.1 21.24 102.2 2.62 3.48
CFM 4507 25 120.3 9.92 84.6 .67 .89 146.4 12.07 89.9 .94 1.26 172.6 14.23 95.3 1.26 1.68 198.8 16.39 100.6 1.61 2.15
RPM 1100 30 112.9 7.76 83.1 .42 .57 139.1 9.56 88.4 .61 .82 165.3 11.35 93.8 .83 1.10 191.4 13.15 99.1 1.07 1.43
HP 1/4 40 98.3 5.06 80.1 .19 .26 124.4 6.41 85.4 .29 .39 150.6 7.76 90.8 .41 .55 176.7 9.11 96.1 .54 .72
50 83.6 3.44 77.1 .09 .13 109.7 4.52 82.4 .15 .21 135.9 5.60 87.8 .22 .30 162.1 6.68 93.1 .31 .41
60 68.9 2.37 74.1 .05 .06 95.0 3.26 79.4 .08 .11 121.2 4.16 84.8 .13 .17 147.4 5.06 90.1 .18 .24
10 166.9 34.40 90.5 6.75 8.98 — — — — — — — — — — — — — — —
15 158.1 21.73 88.9 2.86 3.82 188.9 25.95 94.5 3.92 5.22 219.6 30.17 100.2 5.12 6.80 250.3 34.40 105.8 6.45 8.57
280-P-L 20 149.4 15.40 87.3 1.51 2.01 180.1 18.56 92.9 2.10 2.80 210.9 21.73 98.6 2.77 3.69 241.6 24.90 104.2 3.52 4.69
CFM 5040 25 140.7 11.60 85.7 .89 1.19 171.4 14.13 91.3 1.26 1.68 202.1 16.66 97.0 1.69 2.25 232.9 19.20 102.6 2.17 2.89
RPM 1100 30 131.9 9.06 84.1 .57 .75 162.7 11.18 89.7 .82 1.09 193.4 13.29 95.4 1.11 1.48 224.1 15.40 101.0 1.44 1.92
HP 1/2 40 114.5 5.90 80.9 .26 .34 145.2 7.48 86.6 .39 .52 175.9 9.06 92.2 .55 .73 206.6 10.65 97.8 .73 .97
50 97.0 4.00 77.7 .12 .17 127.7 5.26 83.4 .20 .27 158.4 6.53 89.0 .30 .40 189.2 7.80 94.6 .41 .54
60 79.5 2.73 74.5 .06 .08 110.2 3.79 80.2 .11 .15 141.0 4.84 86.5 .17 .23 171.7 5.90 91.4 .24 .32
15 184.9 25.41 89.9 3.84 5.11 220.9 30.35 95.7 5.26 6.99 256.9 35.30 101.5 6.87 9.13 — — — — —
20 174.6 17.99 88.2 2.02 2.69 210.6 21.70 94.1 2.81 3.74 246.6 25.41 99.9 3.71 4.94 282.6 29.12 105.7 4.73 6.28
336-P-L 25 164.3 13.54 86.6 1.19 1.59 200.2 16.51 92.4 1.69 2.25 236.2 19.48 98.2 2.26 3.01 272.2 22.44 104.0 2.91 3.87
CFM 5700 30 153.9 10.57 84.9 .75 1.00 189.9 13.05 90.7 1.09 1.46 225.9 15.52 96.5 1.48 1.98 261.9 17.99 102.3 1.92 2.56
RPM 1140 40 133.3 6.87 81.5 .34 .45 169.2 8.72 87.4 .52 .69 205.2 10.57 93.2 .73 .97 241.2 12.43 99.0 .97 1.29
HP 3/4 50 112.6 4.64 78.2 .16 .22 148.6 6.12 84.0 .27 .36 184.6 7.61 89.8 .40 .53 220.5 9.09 95.7 .54 .72
60 91.9 3.16 74.9 .08 .11 127.9 4.39 80.7 .15 .20 163.9 5.63 86.5 .23 .30 199.9 6.87 92.3 .32 .43
15 218.3 29.99 90.5 3.82 5.13 260.7 35.82 96.4 5.24 7.04 303.2 41.66 102.3 6.86 9.20 — — — — —
20 206.1 21.24 88.8 2.01 2.70 248.5 25.61 94.7 2.80 3.76 291.0 29.99 100.6 3.70 4.97 333.5 34.36 106.6 4.72 6.33
384-P-L 25 193.9 15.98 87.1 1.18 1.59 236.4 19.49 93.0 1.68 2.26 278.8 22.99 98.9 2.25 3.03 321.3 26.49 104.9 2.90 3.89
CFM 6600 30 181.7 12.48 85.4 .75 1.00 224.2 15.40 91.3 1.09 1.46 266.6 18.32 97.2 1.48 1.98 309.1 21.24 103.2 1.92 2.57
RPM 1140 40 157.3 8.11 82.0 .34 .45 199.8 10.30 87.9 .51 .69 242.3 12.48 93.8 .72 .97 284.7 14.67 99.8 .96 1.29
HP 3/4 50 133.0 5.48 78.6 .16 .22 175.4 7.23 84.5 .27 .36 217.9 8.98 90.4 .39 .53 260.4 10.73 96.4 .54 .72
60 108.6 3.73 75.2 .08 .11 151.1 5.19 81.1 .14 .20 193.6 6.65 87.0 .23 .30 236.0 8.11 93.0 .32 .43
15 272.3 37.42 86.8 5.77 7.85 — — — — — — — — — — — — — — —
20 257.9 26.58 85.3 3.06 4.16 310.532.00 90.5 4.23 5.76 363.1 37.42 95.7 5.57 7.58 — — — — —
500-P-L 25 243.5 20.07 83.9 1.82 2.47 296.1 24.41 89.1 2.56 3.49 348.7 28.75 94.3 3.41 4.65 401.3 33.08 99.4 4.37 5.94
CFM 9380 30 229.1 15.74 82.5 1.16 1.58 281.7 19.35 87.7 1.67 2.27 334.3 22.97 92.8 2.25 3.07 386.9 26.58 98.0 2.91 3.96
RPM 1160 40 200.2 10.32 79.7 .53 .73 252.8 13.03 84.8 .80 1.09 305.4 15.74 90.0 1.12 1.52 358.0 18.45 95.2 1.48 2.01
HP 1-1/2 50 171.4 7.06 76.8 .27 .36 224.0 9.23 82.0 .43 .58 276.6 11.40 87.2 .62 .84 329.2 13.57 92.3 .84 1.14
60 142.6 4.90 74.0 .14 .19 195.2 6.70 79.2 .24 .32 247.8 8.51 84.3 .36 .49 300.4 10.32 89.5 .51 .69
15 330.6 45.43 89.6 5.01 6.54 394.4 54.19 95.3 6.83 8.91 — — — — — — — — — —
20 313.2 32.28 88.0 2.65 3.47 377.0 38.85 93.7 3.68 4.80 440.8 45.43 99.4 4.84 6.32 504.652.00 105.2 6.14 8.00
600-P-L 25 295.8 24.39 86.5 1.58 2.07 359.6 29.65 92.2 2.23 2.91 423.4 34.91 97.9 2.97 3.87 487.2 40.17 103.6 3.79 4.95
CFM 10,300 30 278.4 19.13 84.9 1.01 1.32 342.2 23.51 90.6 1.45 1.90 406.0 27.89 96.3 1.96 2.56 469.8 32.28 102.0 2.53 3.30
RPM 1160 40 243.6 12.55 81.8 .46 .61 307.4 15.84 87.5 .70 .92 371.2 19.13 93.2 .97 1.27 435.0 22.41 98.9 1.29 1.68
HP 1-1/2 50 208.8 8.61 78.7 .23 .30 272.6 11.24 84.4 .37 .49 336.4 13.87 90.1 .54 .70 400.2 16.50 95.8 .73 .95
60 174.0 5.98 75.6 .12 .16 237.8 8.17 81.3 .21 .27 301.6 10.36 87.0 .31 .41 365.4 12.55 92.7 .44 .58
15 397.9 54.68 90.8 5.60 7.67 — — — — — — — — — — — — — — —
20 376.9 38.84 89.2 2.97 4.06 453.7 46.76 95.1 4.11 5.63 530.6 54.68 101.1 5.41 7.42 607.4 62.60 107.0 6.86 9.42
720-P-L 25 355.9 29.34 87.6 1.77 2.41 432.7 35.67 93.5 2.49 3.40 509.6 42.01 99.5 3.32 4.54 586.4 48.34 105.4 4.24 5.82
CFM 11,900 30 334.8 23.00 85.9 1.13 1.54 411.7 28.28 91.9 1.62 2.21 488.5 33.56 97.8 2.19 2.99 565.4 38.84 103.8 2.83 3.87
RPM 1165 40 292.7 15.08 82.7 .52 .70 369.6 19.04 88.6 .78 1.06 446.4 23.00 94.6 1.09 1.48 523.3 26.96 100.5 1.44 1.96
HP 3 50 250.7 10.33 79.4 .26 .35 327.5 13.50 85.4 .42 .56 404.4 16.67 91.3 .60 .82 481.2 19.83 97.3 .82 1.11
60 208.6 7.17 76.2 .13 .18 285.4 9.80 82.1 .23 .31 362.3 12.44 88.1 .35 .48 439.1 15.08 94.0 .49 .67
